Prices ESW®-Mini 032 (hol 550) HOLTHAUSEN ELEKTRONIK Italy

BRAND	HOLTHAUSEN ELEKTRONIK
Product	ESW®-Mini 032 (hol 550)
Internal code	PRT4696212
Weight	0.4
Custom code	90318080
Technical specification	Electronic vibration monitor Operating voltage 24V DC 10% Current consumption max. 45mA Temperature range 0°C to 65°C Protection class IP 65 Die-cast aluminum housing (AlSi12), powder-coated (RAL 7001) Neoprene cover gasket Case dimensions 98 x 34 x 64mm (W x H x D) Weight approx. 400 g (without cable), approx. 560g (with cable) Connection cable 2m, SD 90 C/Kaweflex 6430 SK-C, 7 x 0.34mm², on the device side firmly connected, suitable for outdoor use and oily environment, jacket material: PUR/PUR, min. bending radius: 50.25mm/53.25mm Cable fitting M16x1.5, CuZn39Pb3 brass, nickel-plated Lamellar insert: polyamide PA6 V-2 Sealing ring: CR/NBR polychloroprene nitrile rubber O-ring: nitrile rubber NBR Sensor integrated acceleration sensor Input variable oscillation acceleration Measurement variable Vibration Velocity in mm/s Measurement range 0 to 50mm/s Arithm signal weighting Mean value, adjusted to RMS Frequency range 10Hz to 1kHz (-3dB) Butterworth filter, 40dB/dek or 12dB/oct analog output 4 to 20mA, constant current, proportional to the measurement range Load resistance max. 500 ohms Switching output potential-free switching contact (30V, 1A) Switching threshold 10% to 100% of the measurement range, adjustable in 10% steps via rotary switches in the housing Switching delay response delay 3s fixed Waste delay 0.5s fixed Line monitoring During normal operation, the relay is energized, the switching contact is closed. In case of alarm, loss of voltage or If the cable breaks, the relay falls back into its rest position. Cable layout pink +Ub blue Dimensions brown opener yellow closer green center contact grey analog output white analog mass Screen on case, not connected to ground Optional threaded pin M8x25mm, V4A

HOLTHAUSEN ELEKTRONIK - ESW®-Mini 032 (hol 550) referenced product produced by high technology.
ESW®-Mini 032 (hol 550) became irreplaceable of foundations. ESW®-Mini 032 (hol 550) referenced product which is satisfy the customer's needs, offers advantages of quality and cost. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. We present you the most competative price and delivery time on ESW®-Mini 032 (hol 550) referenced product.

Where can I buy ESW®-Mini 032 (hol 550) by HOLTHAUSEN ELEKTRONIK in Italy?

You can purchase ESW®-Mini 032 (hol 550) by HOLTHAUSEN ELEKTRONIK from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the ESW®-Mini 032 (hol 550)?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of HOLTHAUSEN ELEKTRONIK in Italy?

While we are not the official distributor or seller of HOLTHAUSEN ELEKTRONIK in Italy, we source our products from reliable channels and offer you original HOLTHAUSEN ELEKTRONIK equipment at competitive prices.

How can I access ESW®-Mini 032 (hol 550) catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for ESW®-Mini 032 (hol 550) on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for ESW®-Mini 032 (hol 550)?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
