Prices G052.001330.010.009.010 / A52421002.012XX GSR Italy

BRAND	GSR
Product	G052.001330.010.009.010 / A52421002.012XX
Description	Solenoid valve with coil and connector
Internal code	PRT4016837
Weight	0.5
Custom code	84818079
Technical specification	for connection to 24V DC referenza52421002.012xx consists of: 052.001330 2/2-way solenoid valve Item name: A5242/1002/.012 Control type: directly operated, differential pressure min. 0 bar Construction: seat valve with nipple Seal Function: NC - closed without current Connection: 1/4" cyl. IG according to ISO 228/1 Seat: 2.0 mm Pressure: 0 - 90 bar Temperature (medium): -10°C/+80°C Temperature (ambient): -10°C/+35°C Viscosity (max.): 22 mm²/s Material (in contact with media): Brass 2,0401 Material (in contact with media): Brass 2,0401 KM Installation: Drive in a horizontal or upright position B0051.000059 Magnetic coil Type: 1012 (K0510110) Voltage: 24V DC Dust/water protection: IP65 Power: 18.5W Operating time: 100% ED Connection type: device plug in accordance with DIN 43650-A ISO4400 B0040 000047 Standard plug without wiring, unassembled in a plastic bag Cable socket: 28x28mm Standard: in accordance with EN175301-803 Form A Cable pressure screw: M20 x 1.5 Possible connection cables: Ø5 - 8mm/Ø8 - 10mm Maximum cable cross section: 1.5mm² Voltage: 0 - 250V AC/DC Max. current: 10 A Temperature range: -40 to + 90 °C Housing material: PA6 GF/black Fire protection class: HB-UL94 Housing and contact holder

You can find the current prices belongs to GSR - G052.001330.010.009.010 / A52421002.012XX coded Solenoid valve with coil and connector product. You can ask all the codes and references except G052.001330.010.009.010 / A52421002.012XX too. We are one of the few companies which can present an offer for this product. It produced result of tests of laborotory for years. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy G052.001330.010.009.010 / A52421002.012XX by GSR in Italy?

You can purchase G052.001330.010.009.010 / A52421002.012XX by GSR from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the G052.001330.010.009.010 / A52421002.012XX?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of GSR in Italy?

While we are not the official distributor or seller of GSR in Italy, we source our products from reliable channels and offer you original GSR equipment at competitive prices.

How can I access G052.001330.010.009.010 / A52421002.012XX catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for G052.001330.010.009.010 / A52421002.012XX on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for G052.001330.010.009.010 / A52421002.012XX?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
