Prices C102-G132S4-L80/25G ( B3-00-A) HIMMEL Italy

BRAND	HIMMEL
Product	C102-G132S4-L80/25G ( B3-00-A)
Description	HIMEL® worm gear motor
Internal code	PRT3899030
Weight	165
Custom code	85015220
Technical specification	Art.Nr.2230013040 HIMMEL®-Schneckengetriebemotor C102-G132S4-L80/25G Gewicht: 165 kg St. Maßblatt: C04 Getriebebauart / Type: HIMMEL®-Schneckengetriebemotor / HIMMEL®-worm gear Getriebetyp / Type: C102-G132S4-L80/25G Maßbild / Dimension sheet: C04 Abtriebsdrehzahl / Output speed [1/min; 1/rpm]: 30.50 Übersetzung / Ratio [i]: 47.47 Farbe / colour: RAL 5015 Himmelblau 2K / Sky blue 2K-PUR Schutzart / protection class: IP55 Bauform / mounting position: B3-00-A Abtriebsmoment / Output torque [Nm]: 1479.0 Drehrichtung Abtrieb/Output direction of rotation: links / left Abtriebswelle Getriebe / Output shaft [mm; Zoll]: V60x120 Lagerung Getriebe / Bearing: zugeordnete Lagerung / assigned bearings Ölart / Oil type: CLP PG 460 Synth.oil Ölmenge / Oil quantity [l]: 5.50 Wellenwerkstoff / Shaft material: C45 Abdichtung Getriebe / Sealing: Wellendichtring (WDR) / shaft seal ring Elektrische Ausführung / Elektrical design: CE Polzahl / Poles: 4 Nennfrequenz / Nominal frequency [Hz]: 50 Nennspannung / Nominalvoltage [V]: 380-420/660-690 Nennleistung / Nominalpower [kW]: 5.5 Motordrehzahl nenn / Motor speed nom. [1/rpm]: 1450 Nennstrom / Nominal current In [A]: 11.70/6.80 KK-Lage / Terminal box position: 1A KK-Ausführung / Terminal box type: Aluminium / aluminium Wicklungsschutz / Motor protector: ohne / without Abtriebswelle Motor / Output shaft [mm; Zoll]: V22x33.5 Abdichtung Motor / Sealing motor: normal / normal Isolationsklasse / Insulation class: F Betriebsart / Duty type: S1 Lüfter / Fan: Kunststoff / plastic Bremssteuerspg / Brake supply voltage [V]: 190-240 Überwachung / Monitoring: ohne / without

HIMMEL - C102-G132S4-L80/25G ( B3-00-A) referenced HIMEL® worm gear motor product produced by high technology.
C102-G132S4-L80/25G ( B3-00-A) became irreplaceable of foundations. C102-G132S4-L80/25G ( B3-00-A) referenced product which is satisfy the customer's needs, offers advantages of quality and cost. You can find the most competitive prices about endustriel accessories in our company. Contact us if you are looking for alternative price of C102-G132S4-L80/25G ( B3-00-A) .

Where can I buy C102-G132S4-L80/25G ( B3-00-A) by HIMMEL in Italy?

You can purchase C102-G132S4-L80/25G ( B3-00-A) by HIMMEL from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the C102-G132S4-L80/25G ( B3-00-A)?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of HIMMEL in Italy?

While we are not the official distributor or seller of HIMMEL in Italy, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.

How can I access C102-G132S4-L80/25G ( B3-00-A) catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for C102-G132S4-L80/25G ( B3-00-A) on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for C102-G132S4-L80/25G ( B3-00-A)?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
