Prices W.Nr. 110.020 / MV 5214 RTK Regeltechnik Italy

BRAND	RTK Regeltechnik
Product	W.Nr. 110.020 / MV 5214
Description	motor control valve
Internal code	PRT4893022
Weight	15
Technical specification	Motor control valve - MV 5214 series in continuous form nominal size DN 50, nominal pressure PN 16 Housing material ductile iron EN-GJS-400-18-LT Flanges with DIN sealing surface Spindle sealing: Bellows with PTFE safety plug Characteristic/flow rate: equal percent/below the cone parabolic cone, metallic sealing Kvs value = 37 m³/h, stroke 30 mm Seat diameter 50 mm Surface treatment with zinc dust primer CE marking in accordance with Pressure Equipment Directive (PED) max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 350 °C Electrical actuator - type ReAct 30E-074 Positioning force 3 kN, including manual adjustment 230 V 50/60 Hz AC motor setting speed 0.74 mm/s, stroke 30 mm Protection class IP 65 additional equipment: - additional limit switches (2 pieces) - Potentiometer 1000 ohms

RTK Regeltechnik - W.Nr. 110.020 / MV 5214 referenced motor control valve product produced by high technology.
W.Nr. 110.020 / MV 5214 became irreplaceable of foundations. All of the listed products are with guaranteed origin and high quality. You can find the most competitive prices about endustriel accessories in our company. We present you the most competative price and delivery time on W.Nr. 110.020 / MV 5214 referenced product.

Where can I buy W.Nr. 110.020 / MV 5214 by RTK Regeltechnik in Italy?

You can purchase W.Nr. 110.020 / MV 5214 by RTK Regeltechnik from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the W.Nr. 110.020 / MV 5214?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of RTK Regeltechnik in Italy?

While we are not the official distributor or seller of RTK Regeltechnik in Italy, we source our products from reliable channels and offer you original RTK Regeltechnik equipment at competitive prices.

How can I access W.Nr. 110.020 / MV 5214 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for W.Nr. 110.020 / MV 5214 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for W.Nr. 110.020 / MV 5214?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
