Prices  VX2 128B3  Verlinde  Italy

Rated capacity 125 kg

Height of lift 3 m

Load chain DAT chain

Reeving 01

Hoisting speed 8/2 m/min

Hoisting motor power 0.36 kW

Hoisting engine - nominal current 1.6/1.2 A

Hoisting engine - starting current 4.64/1.32 A

Hoist Duty Group M6

Hoist duty class EN 14492-2 A7/Dh2

Hoist suspension bracket long

Trolley type None

Main voltage 400 V

Phase count 3 Phases

Frequency 50 Hz

Control voltage 48 V

Pendant cable length 2.5 m

Chain bag Yes

Protection class IP55

Mechanical overload device Friction torque limiter

Standard temperature range -20°C to +40°C with rated load and speed (ED 60%, 300 start/hr)

Hoisting limit switch Electrical upper & lower limit switch (2 steps)

Paint 5 years guaranteed RAL 7021

Standard maximum humidity 90%

Control pendant Remco 2 button pendant with emergency stop

Approx. hoist weight including options 26 kg

C-dimension (headroom) 406 mm

Overheating protection for hoisting motor included

Hoist Options:

Chain lubrication grease

Chainbag Standard

Documents:

Number of documents in package 1

Language of documents English (EN)

Document delivery Documents to be shipped with the material
