Prices UT219DS UNI-T Italy

BRAND

UNI-T

Product

UT219DS

Description

Digital Clamp Multimeter

Internal code

PRT4424032

Weight

0.31

Technical specification

Specifications	Range	UT219DS
AC current (A)	600A	±(1.8%+6)
DC current (A)	600A	±(1.8%+6)
AC voltage (V)	600V	±(1%+6)
DC voltage (V)	600V	±(0.6%+3)
LoZ ACV	600V	±(2.5%+6)
Resistance (Ω)	60MΩ	±(1%+3)
Capacitance (F)	60mF	±(4%+7)
Frequency (Hz)	600Hz~40MHz	±(0.1%+6)
Duty cycle	0.1%~99.9%	±(2.6%+7)
Temperature	-40~1000℃	±(2%+5℃)
-40~1832℉	±(2%+9℉)
Features
Display count		6000
Auto/Manual range		√
Jaw opening		33mm
True RMS		√
AC current frequency response		40Hz~400Hz
AC voltage frequency response		40Hz~1kHz
3-phase motor sequence test	600V	√
Low pass filter	1kHz, 3db attenuation	√
V+A displays voltage and current at the same time		√
Diode test		3V
Measurement sampling rate		5 times/s
Analog bar sampling rate		20 times/s
Analog bar		31 segment
Display interface (LCD)		Dual
Auto power off/MAX/MIN		√
Low battery indication		√
Data hold (H)/Relative mode (REL)		√
ZERO mode		√
Function selection (SELECT)		√
Auto backlight/2m drop test		√
IP rating		IP54
Input impedance	≥10MΩ	√
General Characterisitics
Power	1.5V battery (R03) x 3
Display	35mm x 31mm
Product color	Red and grey
Product net weight	310g
Product size	234.6mm x 82mm x 47mm
Standard accessories	Test leads, batteries, carrying bag, PC software CD, point contact temperature probe
Standard individual packing	Gift box, blister, English manual (German, French, Spanish optional)

UNI-T - UT219DS referenced Digital Clamp Multimeter product produced by high technology.
UT219DS became irreplaceable of foundations. Our company supply UT219DS referenced product fastest and securest on your request. You can find the most competitive prices about endustriel accessories in our company. We present you the most competative price and delivery time on UT219DS referenced product.

Where can I buy UT219DS by UNI-T in Italy?

You can purchase UT219DS by UNI-T from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the UT219DS?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of UNI-T in Italy?

While we are not the official distributor or seller of UNI-T in Italy, we source our products from reliable channels and offer you original UNI-T equipment at competitive prices.

How can I access UT219DS catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for UT219DS on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for UT219DS?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
