Prices 803/60-V / 24703526040641R-018816 Schniewindt Italy

BRAND	Schniewindt
Product	803/60-V / 24703526040641R-018816
Description	air heater
Internal code	PRT5107523
Weight	950
Technical specification	24703526040641R-018816 CSN® air heater skid 803/60-V 60 kW, 400 V 3~ with fan Technical data: ******************************* CSN air heater skid consisting of: - skid (right version) - air heater of the series 803 - Compensator - ventilator with filter fully assembled ***************************** CSN air heaters of the 803 series meet tightness class D based on DIN EN 1507/DIN EN 12237. ************************************* drawing number 2218* drawing number 44 ******************************* Electrical data Total power (kW) 60 Power tolerance (%), based on hot power +5/-10 Supply voltage (V) 400 V 3~ circuit star steps 1 x 42kW 1 x 18kW Protection class IP 65 ***************************** operating conditions medium air operating pressure (bar g) max. 0.05 flow rate 720 Nm³/h at 40 mbar inlet temperature (°C) 0 outlet temperature (°C) 250 ***************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************** design data allowed Min./max. temp. TS (°C) 0/+ 500 allowable min./max. pressure PS (bar g) 0/0.05 ***************************** Heating element Tubular heater Number of heating elements 30 diameter (mm) 11.5 closure type { GISO-G Heating element material 1.4828 Length heating elements (mm) ~ 2600 unheated length (mm) 280 Surface load (W/cm²) 2.75 Cooling section with cooling section Length (mm) 200 Heating elements connection screwed in threaded nipple soldered stainless steel ******************** ***** temperature measurement 2 pcs Temperature limiter 230-650°C 230V~; 16A (Ø8 x 2000) per level 1 piece thermally connected ***************************** mechanical structure cross section (W x H mm) 300 x 300 length (mm) 1300 (+ 194 entry/ 206 outlet) entry port Nned for compensator and ventilator outlet connector 8 inches; 150 lbs. material 1.4301 spacer without cable screws pcs M40, 1 pc M25, 2 pcs M20 Junction box (W x H x D mm) 1200 x 350 x 170 Material/Color 1.4301 Other: Type: LM-therm LH3002 (Item No: 230500LAL0F) ***************************** Seal Seal Seal not included Note - with approx. 120mm insulation Insulation surround: aluminum sheet - Includes flanges for pressure and temperature measurement (sensors for pressure and temperature not included). ***************************** ********************* ******** ************************* With centrifugal fan type DMXE050 GR270; 3kW; 230/400V/IP55 according to data sheet fully assembled with vibration dampers A filter with cover is mounted at the fan inlet. ***************************** between heater and ventilator is a fabric compensator assembled ***************************** The whole is mounted on a galvanized steel frame (2500 x 1100mm) with step bars. *******************************

Schniewindt - 803/60-V / 24703526040641R-018816 referenced air heater product produced by high technology.
803/60-V / 24703526040641R-018816 became irreplaceable of foundations. 803/60-V / 24703526040641R-018816 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for 803/60-V / 24703526040641R-018816 Schniewindt . Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy 803/60-V / 24703526040641R-018816 by Schniewindt in Italy?

You can purchase 803/60-V / 24703526040641R-018816 by Schniewindt from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the 803/60-V / 24703526040641R-018816?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Schniewindt in Italy?

While we are not the official distributor or seller of Schniewindt in Italy, we source our products from reliable channels and offer you original Schniewindt equipment at competitive prices.

How can I access 803/60-V / 24703526040641R-018816 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 803/60-V / 24703526040641R-018816 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 803/60-V / 24703526040641R-018816?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
