Prices TL3A0-FC Mecon Italy

BRAND	Mecon
Product	TL3A0-FC
Internal code	PRT4926057
Weight	1.3
Custom code	90261081
Technical specification	Turbo-Lux 3 DN65 100 GPM KIT Description: Turbo-Lux 3 workings Measurement principle: Diaphragm as differential pressure transmitter with bypass flow meter flow direction: arbitrary, taking into account the direction of the arrow Installation position: any Measurement accuracy Measurement deviation: ±2.0% of the end value of the measurement range (FM) ± 5.0% of measurement value (LPCB) ±2.5% of the final measurement range value (vDS) process conditions Nominal size: 2 1/2"/DN 65 (ø 76.1 mm) grooved Pump rated power: 100 usGpm Inlet and outlet distance:5 x D and 2 x D Display range: 40 — 200 usGPM 150 - 750 lpm Installation length: 100 mm (+0.0 mm/-2.0 mm) operating conditions Medium: water Operating temperature: +4 to +50 °C max. operating pressure: FM 500 psi (34.5 bar) LPCB/ VdS PN 16 (232 psi) Constructive structure Case tube: stainless steel Differential pressure collection tube: brass Floater: stainless steel Bypass valve: stainless steel Filter screen: stainless steel Filter screen: stainless steel Seal: NBR Certificates/Approvals FM LPCB VdS Measurement accuracy certificate (bypass meter): with AL: N ECCN: N PREF-J: ALL

You can find the current prices belongs to Mecon - TL3A0-FC coded product. You can ask all the codes and references except TL3A0-FC too. All of the listed products are with guaranteed origin and high quality. It produced result of tests of laborotory for years. Make an offer to us for TL3A0-FC please contact us.

Where can I buy TL3A0-FC by Mecon in Italy?

You can purchase TL3A0-FC by Mecon from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the TL3A0-FC?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Mecon in Italy?

While we are not the official distributor or seller of Mecon in Italy, we source our products from reliable channels and offer you original Mecon equipment at competitive prices.

How can I access TL3A0-FC catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for TL3A0-FC on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for TL3A0-FC?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
