| BRAND | HIMMEL technologies |
| Product | TM165.1 x 450 "BS" |
| Description | drum motor |
| Internal code | PRT4724211 |
| Weight | 40 |
| Custom code | 8501 5220 |
| Technical specification | Product number 5670002480 D=163 mm Drum design/Type: HIMMEL® drum motor/HIMMEL® drum motor Drum type/ Type: TM165.1x450"BS” Drum diameter: Ø 163 Length/lenght [mm]: 450 Drum shape/Drumshell design: cylindrical/cylindrical Rated power/ Nominal power [kW]: 1.1 Rated speed/Nominal speed [m/s]: 0.78 Rated voltage/Nominal voltage [V]: 380-420 Nominal frequency/Nominal frequency [Hz]: 50 Number of phases: 3~ Operating mode/Duty type: S1 Electrical version/Electrical design: CE Insulation class/Insulation class: F Winding protection/ Motor protector: WT 120°C Protection class: IP66 Connection [cover/jacket]: pinned/pinned Electric connection type/elec. connection mode: [B] plastic elbow fitting/Angular cable Gland from plastic Electrical connection type/Elec. connection type: PVC robust cable [LAT©] - shielded/cable PVC robust [LAT©] - screened free cable length/free cable length [m]: 5 Cover shape/endshield shape: socket Ø70x10mm (both sides) Shaft dimensions d/e/f/b [mm]: (40) /30x30/30/20 Clamping length EL/Dimension EL [mm]: 490 Material drum/drumshell material: steel/mild steel Material shaft/ Shaft material: steel/mild steel Material cover/caps material: aluminum/aluminum Sealing/Sealing: 2 shaft seals Oil type/Oil type: CLP 100 Miner.oil Circuit diagram/Wiring diagram: A190412 Brake type/Brake type: BFK458-10E Coil voltage/Coil voltage [V]: 24 Interconnection/connection: separate/separate |
Where can I buy TM165.1 x 450 "BS" by HIMMEL technologies in Italy?
You can purchase TM165.1 x 450 "BS" by HIMMEL technologies from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.
What is the price of the TM165.1 x 450 "BS"?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of HIMMEL technologies in Italy?
While we are not the official distributor or seller of HIMMEL technologies in Italy, we source our products from reliable channels and offer you original HIMMEL technologies equipment at competitive prices.
How can I access TM165.1 x 450 "BS" catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for TM165.1 x 450 "BS" on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for TM165.1 x 450 "BS"?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
