Prices 5670001947 HIMMEL Italy

BRAND	HIMMEL
Product	5670001947
Description	drum motor
Internal code	PRT4464812
Weight	36
Technical specification	TM165.1 x 400 0.75 0.37 60Hz Drum design/Type: HIMMEL® drum motor/HIMMEL® drum motor Drum type/type: TM165.1x400 Length [mm]: 400 Drum shape/drum shell design: crowned Rated power/nominal power [kW]: 0.75 Rated speed/nominal speed [m/s]: 0.37 Rated voltage/nominal voltage [V]: 220-240/380-420 Rated frequency/nominal frequency [Hz]: 60 Number of phases: 3~ Operating Mode/ Duty Type: S1 Electrical design/Electrical design: CE Insulation class/ Insulation class: F Winding protection/motor protector: 3WT`s 120°C Degree of protection class: IP66 Connection type/ Electrical connection: straight screw connection 3m shielded cable/ Straight cable gland 3 m screened cable. Key surface position/direction of spanner: vertical/vertical Shaft dimensions/shaft dimensions d/e/f/b [mm]: 40/30/45/20 Clamping length EL/ EL dimension [mm]: 440 Material drum/drum shell material: steel/mild steel Material shafts/shaft material: steel/mild steel Material lid/caps material: aluminium/aluminium Material gap seal/ gap ring material: galvanised steel/ galvanized steel Sealing/sealing: nilos ring LST-O Oil type/oil type: CLP 100 miner.oil Wiring diagram: LAT-07-07-0010

You can find the current prices belongs to HIMMEL - 5670001947 coded drum motor product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. Our company supply 5670001947 referenced product fastest and securest on your request. Our company can make an offer even if we do not distributor of Italy. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy 5670001947 by HIMMEL in Italy?

You can purchase 5670001947 by HIMMEL from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the 5670001947?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of HIMMEL in Italy?

While we are not the official distributor or seller of HIMMEL in Italy, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.

How can I access 5670001947 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 5670001947 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 5670001947?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
