Prices T1070 06 F2 J13 L100 H3 S5 D3 N040 P5 JSP Industrial-Control Italy

BRAND	JSP Industrial-Control
Product	T1070 06 F2 J13 L100 H3 S5 D3 N040 P5
Description	Sensor
Internal code	PRT4937290
Weight	0.6
Custom code	90259000
Technical specification	T1070 … Resistance temperature sensor into thermowell 06 … Temperature sensor 1× Pt100 / 4-wire, sheath material 1.4404 F2 … Accuracy class B according to EN 60751, measuring range -70 to 500 °C J13 … Fitting of the sensor into thermowell, extension piece Ø 14×2,5 mm, material 1.4541 L100 … Nominal immersion of sensor L = 100 mm H3 … Head Al alloy, with high cap for mounting of transmitter with diameter 44 mm, cable outlet M20x1.5 for cable diameter 4 to 12.5 mm, IP 65 S5 … Cold-end of measuring insert with ceramic terminal block diameter 42 mm, embedded pins (according to NAMUR) D3 … Measuring insert diameter D = 6 mm N040 … Extension piece N = 40 mm, Tmax on thread 210 °C P5 … Process connection male thread G1/2"

JSP Industrial-Control - T1070 06 F2 J13 L100 H3 S5 D3 N040 P5 referenced Sensor product produced by high technology.
T1070 06 F2 J13 L100 H3 S5 D3 N040 P5 became irreplaceable of foundations. T1070 06 F2 J13 L100 H3 S5 D3 N040 P5 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. You can find the most competitive prices about endustriel accessories in our company. Contact us if you are looking for alternative price of T1070 06 F2 J13 L100 H3 S5 D3 N040 P5 .

Where can I buy T1070 06 F2 J13 L100 H3 S5 D3 N040 P5 by JSP Industrial-Control in Italy?

You can purchase T1070 06 F2 J13 L100 H3 S5 D3 N040 P5 by JSP Industrial-Control from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the T1070 06 F2 J13 L100 H3 S5 D3 N040 P5?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of JSP Industrial-Control in Italy?

While we are not the official distributor or seller of JSP Industrial-Control in Italy, we source our products from reliable channels and offer you original JSP Industrial-Control equipment at competitive prices.

How can I access T1070 06 F2 J13 L100 H3 S5 D3 N040 P5 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for T1070 06 F2 J13 L100 H3 S5 D3 N040 P5 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for T1070 06 F2 J13 L100 H3 S5 D3 N040 P5?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
