Prices ERC-054004-015188 / ERCT/35-3-400 Schniewindt Italy

BRAND	Schniewindt
Product	ERC-054004-015188 / ERCT/35-3-400
Description	Screw-in radiators
Internal code	PRT4220252
Weight	1.8
Custom code	85161080
Technical specification	ERC-054004-015188 CSN® screw-in heater ERCT/35-3-400 Technical data: ------------ Radiator technical part ------------ Supply voltage [V] 400.00 Total output [kW] 3,000 Standard power tolerance (+5/-10%) Tol. based on heat output Upper heat tolerance (%) 5 Lower heat tolerance (%) -10 Star connection Neutral wire Yes Protection class IP 54 Installation position horizontal Installation length [mm] 350.0 Upper floor installation length [mm] 0 Lower floor installation length [mm] -30 Unheated length [mm] 35 G 1 1/2 screw connection - SW 65 Screw connection material brass ------------ tubular heater ------------ number 3 Diameter [mm] Ø 8.5 mm Curved design Surface load [W/cm²] 5.94 Pipe material 1.4404 Mounting type Soldered Type of closure Giso-G ------------ connection hood ------------ Hood diameter 80 x 80 mm Hood material galvanised steel Swivel shell material polyamide M20 cable connector Cable connector material plastic ------------ Thermostat/ sensor in the heating bundle ------------ Temperature measurement type controller Temperature measurement controller, 0/85°C, E.G.O., 880/6x129 mm, 3-pin, indoor Temperature measurement Interconnection External control Indoor temperature recording setting Sensor protection tube Ø [mm] 8.5 Sensor protection tube material 1.4404 Sensor protection tube wall thickness [mm] 0.5 ------------ accessory ------------ Seal, Nut With Seal Aramid seal material (WS 3820, novapress UNIVERSAL, Aremi,..

Schniewindt - ERC-054004-015188 / ERCT/35-3-400 referenced Screw-in radiators product produced by high technology.
ERC-054004-015188 / ERCT/35-3-400 became irreplaceable of foundations. ERC-054004-015188 / ERCT/35-3-400 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy ERC-054004-015188 / ERCT/35-3-400 by Schniewindt in Italy?

You can purchase ERC-054004-015188 / ERCT/35-3-400 by Schniewindt from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the ERC-054004-015188 / ERCT/35-3-400?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Schniewindt in Italy?

While we are not the official distributor or seller of Schniewindt in Italy, we source our products from reliable channels and offer you original Schniewindt equipment at competitive prices.

How can I access ERC-054004-015188 / ERCT/35-3-400 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for ERC-054004-015188 / ERCT/35-3-400 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for ERC-054004-015188 / ERCT/35-3-400?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
