| BRAND | Aviteq |
| Product | SRA-C50/01-1-1 |
| Description | controller |
| Internal code | PRT445159 |
| Weight | 2.2 |
| Custom code | 85365003 |
| Technical specification | Item no.23765 220.. 240 V 50/60 HZ 6 A IP54 dimensions: 170 x 120 x 114 mm (HxWxD) VIBTRONIC® -S controller for connecting AVITEQ vibrating conveyors. The oscillating width of the conveyor can be adjusted continuously on the connecting device will be. The flow rate adjustment range is almost 0 to 100%. With a complete set of potentiometers to manually adjust the vibration range. Electromagnetic compatibility (EMC) in accordance with the currently valid EC Directive checked. To protect the thyristors in the controller, a super-fast protection (super-fast or ultra-fast). Vibration rate SRA.. 50... 3,000 rpm (in a 50 Hz network) 3,600 min-1 (on a 60 Hz network) SRA.. 100.. 6,000 rpm (in a 50 Hz network) 7,200 min-1 (in a 60 Hz network) Design in aluminum housing 2000mm power cable with angled Schuko plug Network fluctuation compensation ± 10%, the oscillation range remains constant network tolerance, allowable voltage ± 10% Frequency ± 0.5% Proportional change in the oscillation range of the setpoint Activate switch (continuous contact, potential-free) or Voltage signal +24 V (DC) External external control variable inputs 0.. 10 V (DC), 0/4.. 20 mA (DC) Version “.. -2-1" additional sensor input 24V/20mA, PNP (sensor not included) (level check of downstream devices) Switch on/off delay of the sensor function 0.. 20s adjustable by two separate potentiometers Remote monitoring outputs, relay output |
Where can I buy SRA-C50/01-1-1 by Aviteq in Italy?
You can purchase SRA-C50/01-1-1 by Aviteq from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.
What is the price of the SRA-C50/01-1-1?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Aviteq in Italy?
While we are not the official distributor or seller of Aviteq in Italy, we source our products from reliable channels and offer you original Aviteq equipment at competitive prices.
How can I access SRA-C50/01-1-1 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for SRA-C50/01-1-1 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for SRA-C50/01-1-1?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
