| BRAND | CD AUTOMATION |
| Product | RC1180-45AEIO2020 |
| Description | Single Phase Thyristor Controller |
| Internal code | PRT4283698 |
| Weight | 2 |
| Technical specification | Series REVO C 35-800A No: RC1ABC-D-E-F-G-H-I-J-K-L-M (EF external backup, IF internal backup incl.) (ABC) Load timing/Case Type/Dimensions/Weight/Fuse (EF = external backup; IF internal backup) 035:35A SR9 (72x121x185mm) 1.15 kg EF 040:40A SR9 (72x121x185mm) 1.15 kg EF 060:60A SR12 (93x269x170 mm) 3.4 kg IF 090:90A SR15 (93x273x170 mm) 3.6 kg IF 120 120A SR15 (93 x 273 x 170 mm) 3.6 kg IF 150 150A SR15 (93 x 273 x 170 mm) 3.6 kg IF 180:180A SR15 (93 x 273 x 170 mm) 3.6 kg IF 210:210A SR15 (93x273x170 mm) 3.6 kg IF 300:300A S12 (137x520x270 mm) 15 kg IF 400:400A S12 (137x520x270 mm) 15 kg IF 500:500A S12 (137x520x270 mm) 15 kg IF 600:600A S12 (137x520x270 mm) 15 kg IF 700:700 A S12 (137x520x270 mm) 15 kg IF 800:800A S15 (137x560x270 mm) 17.2 kg IF CE only (D) Load voltage max 4:480 V 6:600 V 7:690 V CE only (Attention, the housing types and dimensions change 30A,35A,40A,300A not available) (E) Mains voltage 1:90-135 V AC 2:180-265 V AC 3:238-330V AC 5:342-528 VAC 6:540-759 V AC 7:540-759 V AC (F) Entrance S: SSR B: 0... 20 mA A: 4... 20 mA V: 0-10 V DC K: 10 kOhm Poti (G) Operating mode and soft start (SC Single Cycle, HC Half Cycle, BF Burst Firing, PA Phase section DT Delay Triggering ZC Zero Crossing, NS no soft start, LS linear Softstart, SS Softstart SIR heater) C: SC NS S: SC LS H: HC NS L: HC LS I: HC SS B: BF NS J: BF LS P: PA NS E: PA LS D: DT NS T: DT LS Z: ZC NS R:ZC LS (H) Repatchance 0: without U: Voltage V Q: Voltage V2 I: Electricity I A: Current I2 W: Power VXi (I) Option 0: without X: by datasheet (J) Fan 0: without <90A 1: with 110 V fan (>= 90 A) 2: with 220 V fan (>= 90 A) 3: with fan 240 V (>= 90 A) (K) UL 0: CE Europe L: with cUL Europe + America (L) Load Type for 1 Phase Operation 0: Ehmic load 1: Inrarot short wave 2: mosiC2 heater 3: SiC heater 4: Transformer Loading Secondary Resistive Load 5: Transformer secondary MoSiC2 heater 6: Transformer load secondary SiC2 heater 7: Transformer load secondary UV emitter (M) Communication and analog output (0 without, I 4... 20 mA, U 0... 10 V, UPS External power supply) 0: no1 Modbus RTU, 0 1: no1 Modbus RTU, I 2: no1 Modbus RTU, V 3: no2 Modbus RTU, 0, UPS 4: no2 Modbus RTU, I, UPS 5: no2 Modbus RTU, V, UPS 6: Profibus + Modbus RTU, 0, UPS 7: Profibus + Modbus RTU, I, UPS 8: Profibus + Modbus RTU, V, UPS 9: Profinet + Modbus RTU, 0, UPS A: Profinet + Modbus RTU, I, UPS B: Profinet + Modbus RTU, V, UPS C: Modbus TCP + Modbus RTU, 0, UPS D: Modbus TCP + Modbus RTU, I, UPS E: Modbus TCP + Modbus RTU, V, UPS |
