Prices  RBS-145/SP  Robuschi  Italy

RBS Blower Series
Bare axis size 145
Bare axle mouth (DN) 300
Footless blower port layout
Engine type Without motor
Blower flow direction Standard flow
CE CE certificate
EC Declaration Type II B
ATEX CATEGORY NOT ATEX
Alkyd-hydro 5009 sp50 (std) Machine Painting
Water-soluble Alkyd painting cycle
Total coating thickness (um) 50
Machine RAL code 5009
Blower cooling Air cooling
Machine packaging type Carton on pallet
Painting Machine/Standard Machine Painting Group
G250 cast iron body. GS400-15 ductile iron rotors. Steel shaft
C40. Keep the maze. Oil lubrication.
** Performance tolerance according to Robuschi TE1.S.0015 specification
** (Excluding RBS AV)
** Estimated sound pressure level in the free field at a distance of 1 m with the
acoustically isolated pipes

this is the construction sheet:

Rotary volumetric lobe blower for conveying oil-free atmospheric air
· Three-lobe rotors with rectified profile, statically and dynamically balanced, made of ductile iron GJS 400-15 UNI-EN 1563
· Body with integrated device for dampening LOW PULSE pressure pulsations and reinforced with ribs to eliminate distortions due to loads, built in high-strength gray cast iron GJL 250 UNI-EN 1561
· Reinforced sidewalls with ribs to withstand the loads induced by the trees, made of high-strength gray cast iron GJL 250 UNI-EN 1561
· Integral shafts with rotors made of ductile iron GJS 400-15 UNI-EN 1563 up to size RBS 106 or coupled to the rotors by means of forced coupling and tab, made of C40 UNI-EN 10083/1 steel from size RBS 115 to size RBS 165
· Rolling bearings calculated for a life of 100,000 hours at the maximum speed and pressure conditions specified in the catalog
· Maximum peripheral velocity of the head of the lobes less than 40 m/s
· Synchronism gear with helical tooth wheels and cemented and rectified evolving profile, made of EN-UNI 10084 16 Mn Cr 5 steel, coupled to the shafts by means of forced coupling with a 1:50 cone and with assembly and disassembly with oil under pressure
· Gas seals on each labyrinth-type shaft without creeping elements and without wear with drain holes to limit the pressure inside the oil carters.
· • Oil seals on each shaft by means of an oil seal disc and tile without creeping elements and without wear combined with a labyrinth seal to limit the filament of oil vapors
· Oil seal on the control shaft by means of a lip seal ring made of high-strength elastomer (VITON) and a cemented and ground shaft protection jacket to ensure a high operating life
· Lubrication of all bearings (control side and gear side) and of the synchronizing gear by means of an oil bath with oil spreaders fitted to the drive shaft
