Prices TM165.1 x 800 HIMMEL Italy

BRAND	HIMMEL
Product	TM165.1 x 800
Description	drum motor
Internal code	PRT4640280
Weight	75
Technical specification	Product no. 5670002253 1.50 0.56 “stainless steel” Cable: L3833-9350 shielded 9x1.5mm²/AWM style 21179 105°C 600V E172204 clamping pin on one side with internal thread M10 Dimension sheet: 165-1801-6134 Drum design/ Type: HIMMEL® drum motor/Himmel® drum motor Drum Type/Type: TM165.1x800 Drum diameter/ Drum diameter: Ø 164/165 Length/length [mm]: 800 Drum shape/Drumshell design: crowned Rated power/ nominal power [kW]: 1.5 Rated speed/Nominal speed [m/s]: 0.56 Rated voltage/rated voltage [V]: 230 Rated frequency/Nominal frequency [Hz]: 50 Number of phases: 3~ Operating mode/Duty type: S1 Electrical design/Electrical design: CE Insulation class/ Insulation class: F Winding protection/motor protector: WT 120°C Degree of protection/protection class: IP66 Connection [cover/sheath]: glued/glued Elect.connection/elec. connection mode: [C] -right-angle-straight-/ right-angled-straight Elect.connection type/elec. connection type: cable PVC-robust [LAT©] - shielded/cable PVC robust [LAT©] - screened free cable length/free cable length [m]: 4 cable outlet/cable outlet: bottom/bottom Wrench face location/direction of spanner: vertical/vertical Shaft dimensions/Shaft dimensions d/e/f/b [mm]: 40/30/34/18.5 Clamping length EL/dimension EL [mm]: 837 Material drum/drumshell material: stainless steel/stainless steel Material shafts/Shaft material: stainless steel/stainless steel Material lid/caps material: stainless steel/stainless steel Material gap seal/gap ring material: stainless steel/stainless steel Sealing/Sealing: Nilos ring LST-O Type of oil/Oil type: CLP NSF/H1 100 Oil Schematic/Wiring diagram: LAT-07-07-0015 other extras/other specials: threaded hole in shaft journal/thread in shaft

HIMMEL - TM165.1 x 800 referenced drum motor product produced by high technology.
TM165.1 x 800 became irreplaceable of foundations. We are one of the few companies which can present an offer for this product. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for TM165.1 x 800 HIMMEL . Contact us if you are looking for alternative price of TM165.1 x 800 .

Where can I buy TM165.1 x 800 by HIMMEL in Italy?

You can purchase TM165.1 x 800 by HIMMEL from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the TM165.1 x 800?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of HIMMEL in Italy?

While we are not the official distributor or seller of HIMMEL in Italy, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.

How can I access TM165.1 x 800 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for TM165.1 x 800 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for TM165.1 x 800?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
