Prices PR-SPA-EX-WKF / 901100322000001 Ephy Mess Italy

BRAND	Ephy Mess
Product	PR-SPA-EX-WKF / 901100322000001
Description	Temperature sensor
Internal code	PRT519510
Weight	1
Custom code	90259000
Technical specification	iBEXu 14 ATEX 1281 U, II 2G Ex eb IIC Gb II 2D Extb IIIC Db Screw-in resistance thermometer, M-OK/SGH 1Pt100, 3-wire circuit Class B ±0.3°C at 0°C in accordance with DIN EN 60751 stainless steel, press surround, screw housing, ø6 Step sleeve or socket: ø6x20mm, installation length: 15mm, total length: 50mm, VSB: fixed, stainless steel, M8x1/SW 13x15mm Supply line: shielded hose line 1x [3x0.5mm²-Cu-tin-plated/FEP/polyester film/stainless steel/SI, KL=1500mm, Aø: 6.8mm] RDBN (RD/RD/WH), shrink tube=30mm Measurement range: -50°C... +130°C Ambient temperature: -50°C... +130°C Dielectric strength: 2.5 kV AC. 50 Hz/ 1min. Shield not placed on the sensor housing Umbrella folded down on the connection side three cable clamps, beige

Ephy Mess - PR-SPA-EX-WKF / 901100322000001 referenced Temperature sensor product produced by high technology.
PR-SPA-EX-WKF / 901100322000001 became irreplaceable of foundations. Our company supply PR-SPA-EX-WKF / 901100322000001 referenced product fastest and securest on your request. It produced result of tests of laborotory for years. Contact us if you are looking for alternative price of PR-SPA-EX-WKF / 901100322000001 .
