| BRAND | Schniewindt |
| Product | PAT-044223-031070 |
| Description | CSN® cartridge heater |
| Internal code | PRT4854996 |
| Weight | 3 |
| Custom code | 85161080 |
| Technical specification | 90N/G1½-80-0.75-220 Technical data: Type 90N/G Ceramic type heating element ------------ Radiator technical part ------------ Supply voltage [V] 220.00 Total output [kW] 0.750 Standard power tolerance (+5/-10%) Tol. based on heat output Upper heat tolerance (%) 5 Lower heat tolerance (%) -10 1-phase connection Neutral wire Not relevant Protection class IP 65 Installation position horizontal Installation length [mm] 800.0 Upper floor installation length [mm] 10 Lower floor installation length [mm] -10 Unheated length [mm] 50 ------------ Heater insert mounting ------------ Type of fastening screw G 1 1/2 screw connection - SW 65 Bolting material steel cartridge tube Diameter [mm] Ø 40 mm Material steel Surface load [W/cm²] 0.80 pottery ------------ Ceramic diameter 35 ------------ Tubular heater Ohne/not relevant connection hood Hood diameter 61 x 68 mm Hood material galvanised steel M20 cable connector Cable connector material plastic Cable fitting position Radial Thermostat without/not relevant operating conditions: Hydraulic oil medium Operating temperature [°C] 40 Maximum allowable temperature (TS) [°C] 80 Ambient temperature min. [°C] -20 Ambient temperature max. [°C] 40 Maximum allowable pressure (hp) [barg] 0.5 Operating pressure [barg] 0,5 Compliance with guideline Ohne, < 0.5 bar (g) |
Where can I buy PAT-044223-031070 by Schniewindt in Italy?
You can purchase PAT-044223-031070 by Schniewindt from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.
What is the price of the PAT-044223-031070?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Schniewindt in Italy?
While we are not the official distributor or seller of Schniewindt in Italy, we source our products from reliable channels and offer you original Schniewindt equipment at competitive prices.
How can I access PAT-044223-031070 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for PAT-044223-031070 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for PAT-044223-031070?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
