| BRAND | Microscan |
| Product | MS 3-0003 |
| Description | Laserscanner |
| Internal code | PRT967963 |
| Weight | 1 |
| Technical specification | Laserscanner, Raster, Low Density Decodes/second: up to 1000 Read range: 51 to 254 mm Wide scan angle IP54 enclosure Compact & Lightweight: The 44.5 mm square by 21.6 mm tall scanner weighs only 57 g for easy mounting onto robotic equipment or into tight spaces. High Scan Speed: Adjustable scan speed from 300 up to 1000 decodes per second and Omron Microscan’s world-class decode algorithms ensure accurate reading every time, at a read range of 51 to 254 mm. Wide Scan Angle: The wide scan angle of over 70 degrees and a factory customizable focal point add up to space savings within your system, allowing greater flexibility with positioning. Visible Indicators: Illuminated LEDs on top of the scanner provide visual confirmation of the scanner performance. Real-time Controls: The inputs include a trigger signal, a “new master” input, and a programmable input for resetting counters or releasing outputs. The outputs can be configured to activate upon a variety of conditions including matchcode and diagnostic operations. |
