Prices MI-DM0113 DM1133-C++13BZE8EAA-307mm Interroll Italy

BRAND	Interroll
Product	MI-DM0113 DM1133-C++13BZE8EAA-307mm
Description	motor
Internal code	PRT4966340
Weight	15.3
Technical specification	Product name DM 0113 3-phase asynchronous Protection level IP 69K Tube length (SL) 300.0 mm Drum width (FW) 307.0 mm Installation length (EL/LW/BF) 320.0 mm Overall axle length (AGL) 370.0 mm Power 225 W coil number of poles 2 Torque [Nm] 11.2 Band tensile force 195 N Gear ratio (i) 16.00 Transmission Material description Cast iron: GGG-40 Speed at frequency 1 1.04 m/s Frequency 1 50 Hz external connection diagram M45+70 high voltage 400 V low voltage 230 V Rated current, high voltage 0.56 A rated current, low voltage 0.96 A Speed at frequency 2 1.24 m/s Frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Stainless steel pipe material: 1.4301/304 Pipe diameter (A) 115.0 mm Pipe diameter (B) 115.0 mm Wedge steel tube shape Pipe option type without wedge steel Pipe option wedge steel 8x7mm Cover A version Standard cover B version Standard Cover A Material stainless steel: 1.4301/304 Cover B Material stainless steel: 1.4301/304 Shaft A version standard Ø25mm shaft B version standard Ø25mm Shaft A Material stainless steel: 1.4305/303 Shaft B Material stainless steel: 1.4305/303 Wave A key area (F) 20.0 mm Wave B key area (F) 20.0 mm Wave A key face length (C) 25.0 mm Wave B key face length (C) 25.0 mm Motor option SKF incremental encoder encoder operating voltage 24 V Encoder increments 32 Oil type synthetic food oil Electrical connection terminal box Elek. Connection material stainless steel: 1.4301/304 Option cable length 5.0 m Option cable type shielded; not halogen-free

Interroll - MI-DM0113 DM1133-C++13BZE8EAA-307mm referenced motor product produced by high technology.
MI-DM0113 DM1133-C++13BZE8EAA-307mm became irreplaceable of foundations. MI-DM0113 DM1133-C++13BZE8EAA-307mm referenced product which is satisfy the customer's needs, offers advantages of quality and cost. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for MI-DM0113 DM1133-C++13BZE8EAA-307mm Interroll . Contact us if you are looking for alternative price of MI-DM0113 DM1133-C++13BZE8EAA-307mm .

Where can I buy MI-DM0113 DM1133-C++13BZE8EAA-307mm by Interroll in Italy?

You can purchase MI-DM0113 DM1133-C++13BZE8EAA-307mm by Interroll from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the MI-DM0113 DM1133-C++13BZE8EAA-307mm?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Interroll in Italy?

While we are not the official distributor or seller of Interroll in Italy, we source our products from reliable channels and offer you original Interroll equipment at competitive prices.

How can I access MI-DM0113 DM1133-C++13BZE8EAA-307mm catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MI-DM0113 DM1133-C++13BZE8EAA-307mm on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for MI-DM0113 DM1133-C++13BZE8EAA-307mm?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
