| BRAND | Jesco |
| Product | MEMDOS SMART LD 15 PVC/FPM |
| Internal code | PRT3382922 |
| Weight | 2.2 |
| Custom code | 84135040 |
| Technical specification | 10104006 Step-Motor-driven Diaphragm Dosing Pump Mathcode: 0101D015006AC011A2K2KC1ZC1Z0 Customs Tariff No.: 84135040 Step-motor-driven diaphragm dosing pump Product: MEMDOS SMART Type: LD Flow rate at max. pressure: 13.7 l/h Delivery pressure max.: 6 bar Capacity adjustment: Stroke frequency adjustable: up to 150 strokes/min Material dosing head and valves: PVC Control unit: 110 - 240 V +5/-10 %, 50/60 Hz Electrical connection: 1.8 m mains cable with plug, Europe (for 230 V AC) Suction valve DN4: Double-ball ceramic/PVDF/FPM (ball/seat/gasket) Discharge valve DN4: Double-ball ceramic/PVDF/FPM (ball/seat/gasket) Material suction connection: PVC Suction connection: Hose clamp connection set 4/6, 6/9 and 6/12 Material discharge connection: PVC Discharge connection: Hose clamp connection set 4/6, 6/9 and 6/12 Dosing head arrangement: Floor mounting Functions Stroke frequency can be precisely adjusted via the keyboard Graphic display Pulse input (increase and reduction) Level input with early warning and main alarm Release input for external start/stop BIC: GENODE61WTH IBAN: Volksbank Main-Tauber eG DE50 6739 0000 0001 0386 05 Bank details: Mannheim HRB 570419 Registration court: Reg. office: Wertheim RLB Oberösterreich AG Südwestbank Stuttgart Lutz-Jesco GmbH DE42 7402 0100 0008 5003 99 DE18 6009 0700 0425 2430 01 RZOODE77 SWBSDESS Managing director: |
