Prices LD 1 PVC/FPM (10241002) Jesco Italy

BRAND	Jesco
Product	LD 1 PVC/FPM (10241002)
Internal code	PRT3340905
Weight	3.2
Technical specification	MAGDOS LD 1 PVC/FPM Solenoid Diaphragm Dosing Pump Matchcode: 0102D0010BC011A2K2KC1ZC1Z0 Customs Tariff No.: 84135040 Net Weight: 3,2 kg Control unit: 230 V AC, 50/60 Hz Electrical connection: 1.8 m mains cable with plug, Europe (for 230 V AC) Suction valve DN3: Double-ball ceramic/PVDF/FPM (ball/seat/gasket) Discharge Valve DN3: Double-ball ceramic/PVDF/FPM (ball/seat/gasket) Material suction connection: PVC Suction connection: Hose clamp connection set 4/6, 6/9 and 6/12 Material discharge connection: PVC Discharge connection: Hose clamp connection set 4/6, 6/9 and 6/12 Dosing head arrangement: Floor mounting Functions Stroke frequency can be precisely adjusted via the keyboard Graphic display Pulse input (increase and reduction) with connection cable Level input with early warning and main alarm Release input for external start/stop Solenoid-Diaphragm Dosing Pump Product: MAGDOS Type: LD Delivery rate: 0.76 l/h at 16 bar - 1.1 l/h at 8 bar Capacity adjustment: Stroke frequency adjustable: up to 250 strokes/min Material dosing head and valves: PVC

Jesco - LD 1 PVC/FPM (10241002) referenced product produced by high technology.
You can ask all the codes and references except LD 1 PVC/FPM (10241002) too. We are one of the few companies which can present an offer for this product. It produced result of tests of laborotory for years. Contact us if you are looking for alternative price of LD 1 PVC/FPM (10241002) .
