Prices KL75.01-SB/2 Re + M12K HIMMEL Italy

BRAND	HIMMEL
Product	KL75.01-SB/2 Re + M12K
Description	flat engine
Internal code	PRT3418583
Weight	30
Technical specification	2140000741 AS 4 x M6 Maßblatt: 1NJ100000000143 K-Modellreihe / Design series: KL75.01 Typ / Type: KL75.01-SB/2-M12K K-Maßblatt / dimension sheet: 1NJ100000000143 Farbe / Colour: RAL 6011 Resedagruen 2K / Reseda green 2K-PUR Bauform / Mounting position: B3 Schutzart / Protection class: IP54 K-Leistungsschild / Name plate: Klebeschild 29x53 Leistungsschild Logo / Name plate Logo: Himmel W.Durchmesser / shaft diameter: 30,0 mm W.Länge / shaft-length: 54,0 mm (mitte Fußbohrung bis Anfang Werkzeug) Wellengewinde / shaft thread: M20 rechts K-Flanschscheiben Ø / external diameter flange: 120 mm K-Werkzeugbreite / tool width: max. 3 mm K-Besonderheiten 1 / specific feature 1: Lagerschild AS 4xM6 (731862) KK-Ausführung / Terminal box type: Kunststoff - PG16 / plastic-PG16 KK-Lage / Terminal box position: 1B Elektrische Ausführung / Elektrical design: CE Leistung / Power [kW]: 3.7 Motordrehzahl / Motor speed [1/min; 1/rpm]: 2900 Frequenz / Frequency [Hz]: 50 Phasenanzahl /: 3~ Spannung / Voltage [V]: 400 Strom / Current [A]: 7.60 CosPhi / CosPhi: 0.86 Schaltung / Wiring: S102 (D) Betriebsart / Duty type: S1 Wicklungsschutz / Motor protector: 3WT`s 160°C Isolationsklasse / Insulation class: F Schaltbild Motor / Connection diagram motor: A0102000 Schaltbild Einbauten 1 / Con. diagram compon. 1: A01TB000 Bremstyp / Brake type: M12K [12Nm] (L8) Bremssteuerspg / Brake supply voltage [V]: 230 Verschaltung / Connection: nicht am Klemmbrett / not on terminal block Schaltbild Bremse 1 / Connection diagram brake 1: A01BA000 Gewicht pro Stück: ca. 30,00 Kg

HIMMEL - KL75.01-SB/2 Re + M12K referenced flat engine product produced by high technology.
KL75.01-SB/2 Re + M12K became irreplaceable of foundations. Our company supply KL75.01-SB/2 Re + M12K referenced product fastest and securest on your request. Our company can make an offer even if we do not distributor of Italy. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy KL75.01-SB/2 Re + M12K by HIMMEL in Italy?

You can purchase KL75.01-SB/2 Re + M12K by HIMMEL from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the KL75.01-SB/2 Re + M12K?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of HIMMEL in Italy?

While we are not the official distributor or seller of HIMMEL in Italy, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.

How can I access KL75.01-SB/2 Re + M12K catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for KL75.01-SB/2 Re + M12K on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for KL75.01-SB/2 Re + M12K?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
