| BRAND | HIMMEL |
| Product | K75.01-AM-SB/2-M12K 1"-8UNC-LH |
| Internal code | PRT4850415 |
| Weight | 48 |
| Custom code | 8501 5220 |
| Technical specification | same as type plate number P-743308/1 Dimension sheet: 1NJ000444 K model series/design series: K75 Type/type: K75.01-AM-SB/2-M12K K-size sheet/dimension sheet: 1NJ000444 Colour/colour: RAL 6011 Reseda green 2K/Reseda green 2K-PUR Design/mounting position: B3 K-mounting sides/mounting sides: one-sided foot machining/one-sided foot machining Protection class/ protection class: IP54 K rating plate/name plate: adhesive label 90x60 /adhesive label 90x60 Data plate logo/name plate logo: ACC Customs tariff number/HS code: 85015220 Ambient temperature/Ambient temperature /Ta [°C]: -20/+40 Output variant/Output variant: flange disc/flange plate W.Diameter/ Shaft diameter [mm]: 28.575 W. length/shaft length [mm]: 102 (center foot hole to start of tool/center foot Hole to beginning of tool) Shaft thread: 1" - 8 UNC-L.H. K-flange discs Ø/ external diameter flange [mm]: 140 K tool width/tool width [mm]: 0 - 5 Storage AS/Bearing-AS (DE): Simple bearing BS/Bearing-BS (NDE) storage: simple bearing K-elect.connection type/elec. connection mode: terminal box/ terminal box KK material/ Terminal box material: aluminium/ aluminum KK location/Terminal box position: 3B KK screw connection/gland: (1x) -NPT Label/Approval|Identification/Certification: CE & CSA Number of phases/number of phases: 3~ Identification letter/Code letter: J Number of pins/Poles: 2 Rated power/ Nominal power [kW]: 3.7 Rated power/ Nominal power [HP]: 5 Rated motor speed/ motor speed nom. [1/min; rpm]: 3500 Nominal frequency/ Nominal frequency [Hz]: 60 Rated voltage/nominal voltage [V]: 230/460 Rated current/ Nominal current In [A]: 12.2/6.1 CosPHI/CosPHI: 0.89 Circuit/ Wiring: S200 (YY/Y) Operating mode/Duty type: S 6-75% Operating mode/ Duty type CSA/UL: int. duty S6 7.5 min on, 2.5 min off Supply type/power supply: Network operation/mains operation External grounding motor/External grounding motor: Not available/not existing Winding protection/Motor protector: without/without Insulation class/Insulation class: F Type of ventilation/ Ventilation type CSA/UL: TEFC Motor circuit diagram/Motor connection diagram: A0200000 Integrated circuit diagram 1/Con. diagram compon. 1: A010414 Brake type/ Brake type: M12K [12Nm] (L8) Brake control voltage/brake supply voltage [V]: 206-255 Interconnection/Connection: separate/separate |
Where can I buy K75.01-AM-SB/2-M12K 1"-8UNC-LH by HIMMEL in Italy?
You can purchase K75.01-AM-SB/2-M12K 1"-8UNC-LH by HIMMEL from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.
What is the price of the K75.01-AM-SB/2-M12K 1"-8UNC-LH?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of HIMMEL in Italy?
While we are not the official distributor or seller of HIMMEL in Italy, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.
How can I access K75.01-AM-SB/2-M12K 1"-8UNC-LH catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for K75.01-AM-SB/2-M12K 1"-8UNC-LH on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for K75.01-AM-SB/2-M12K 1"-8UNC-LH?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
