Prices K62-M/2-G4K M6-RH (2150001271) HIMMEL Italy

BRAND	HIMMEL
Product	K62-M/2-G4K M6-RH (2150001271)
Description	HIMMEL® Flatmotor
Internal code	PRT4248632
Weight	15
Technical specification	Number 142812/161 successors Weight: approx. 15.0 kg + packaging Dimension sheet: 1NJ100000000105 K Models/design series: K62 Type/type: K62-M/2-G4K K-dimension sheet /dimension sheet: 1NJ100000000105 Colour: silver green - hammered Type /mounting position: B14 Protection class/protection class: IP54 K rating plate/name plate: adhesive label 90x60 /adhesive label 90x60 Performance label Logo /name plate logo: SKY W.dieter/shaft diameter [mm]: 20 W.Length/Shaft-Length [mm]: 44 (free shaft end/free shaft end) Wave thread/shaft thread: M6-R.H. KK version/Terminal box type: Set KK location/Terminal box position: 2CAK Electrical design: CE Number of phases/number of phases: 3~ Rated wattage/Nominal Power [kW]: 2.2 Nomine/Engine Speed Nom. [1/rpm]: 2700 Nominal Frequency [Hz]: 50 Rated voltage/nominal voltage [V]: 230/400 Rated current/Nominal current In [A]: 9.50/5.50 cosphi/cosphi: 0.83 Circuit/Wiring: S100 (D/Y) Mode of operation/Duty type: S6 -40% Winding protection/Motor protector: 2WT`s 160°C Insulation class/Insulation class: F Schematic Engine/Connection diagram engine: A311001-2 Brake Type: G4K [3Nm] Brake Control Supply Voltage [V]: 230 Interconnection/Connection: on the clipboard/on terminal block

HIMMEL - K62-M/2-G4K M6-RH (2150001271) referenced HIMMEL® Flatmotor product produced by high technology.
K62-M/2-G4K M6-RH (2150001271) became irreplaceable of foundations. K62-M/2-G4K M6-RH (2150001271) referenced product which is satisfy the customer's needs, offers advantages of quality and cost. You can find the most competitive prices about endustriel accessories in our company. Make an offer to us for K62-M/2-G4K M6-RH (2150001271) please contact us.

Where can I buy K62-M/2-G4K M6-RH (2150001271) by HIMMEL in Italy?

You can purchase K62-M/2-G4K M6-RH (2150001271) by HIMMEL from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the K62-M/2-G4K M6-RH (2150001271)?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of HIMMEL in Italy?

While we are not the official distributor or seller of HIMMEL in Italy, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.

How can I access K62-M/2-G4K M6-RH (2150001271) catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for K62-M/2-G4K M6-RH (2150001271) on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for K62-M/2-G4K M6-RH (2150001271)?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
