Prices HGR-RO-050-OR-F-M-S Goudsmit Magnetics Italy

BRAND	Goudsmit Magnetics
Product	HGR-RO-050-OR-F-M-S
Description	Magnetic gripper
Internal code	PRT4785770
Weight	0.21
Custom code	85051100
Technical specification	TPGC050014 HGR-RO-050-OR-F-M-S Product description: magnetic gripper Type: Base size: Ø50 mm Circuit: Pneumatic Rated workload: 18 N (under ideal conditions - with Safety factor 3 according to EN13155) Max. tear-off force: 55 N (under ideal conditions - diagram: see tab Downloads - Influencing factors lifting capacity: see Magnetic Handling) Minimum recommended sheet thickness: 1 mm Interface/connection dimensions: M8 threaded hole Connections: Pneumatic: M5 (2x) Material anti-slip coating/friction ring: NBR 70° Shore A Housing material: aluminum Surface treatment/coating: Anodized color: red Min./max. ambient temperature: 0 to 70 °C Switching pressure: 4 bar (recommended), 6 bar (max.) Air consumption: 0.112 l/cycle (1x up, 1x down) Magnet system: Feinpol Magnet system: 4 permanent magnet poles Magnet quality: neodymium GSN-38, Br 12 600 gauss (at 20 °C), Tmax. 80°C diameter: 50 mm height: 48 mm

You can find the current prices belongs to Goudsmit Magnetics - HGR-RO-050-OR-F-M-S coded Magnetic gripper product. HGR-RO-050-OR-F-M-S became irreplaceable of foundations. It distinguishes with price and quality among the similar products. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for HGR-RO-050-OR-F-M-S Goudsmit Magnetics . Contact us if you are looking for alternative price of HGR-RO-050-OR-F-M-S .

Where can I buy HGR-RO-050-OR-F-M-S by Goudsmit Magnetics in Italy?

You can purchase HGR-RO-050-OR-F-M-S by Goudsmit Magnetics from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the HGR-RO-050-OR-F-M-S?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Goudsmit Magnetics in Italy?

While we are not the official distributor or seller of Goudsmit Magnetics in Italy, we source our products from reliable channels and offer you original Goudsmit Magnetics equipment at competitive prices.

How can I access HGR-RO-050-OR-F-M-S catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for HGR-RO-050-OR-F-M-S on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for HGR-RO-050-OR-F-M-S?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
