Prices GR80 SMT 16B 1000L AXS4 Settima Italy

BRAND	Settima
Product	GR80 SMT 16B 1000L AXS4
Internal code	PRT5103681
Weight	47.5
Technical specification	screw pump with pump carrier and motor GR80 SMT 16B 1000L AXS4" MPT160/213 M160L11N4 B5IE3 400/690V-50Hz Q/P (1450 rpm; 46 mm²/s; 10 bar) =503.89l/min/11.7 kW, NPSH = 3.14mWS Q/P (1450 rpm; 257.6 mm²/s; 10 bar) =513.98 l/min/13.37 kW, NPSH = 4.07 mWS Pump weight: 47.5kg Country of origin: Italy, customs tariff number: 84136070, manufacturer: Settima GR80 = frame size SMT 16B = pressure level 40 bar 1000L = nominal flow with ø38mm cylindrical shaft for installation with pump carrier and coupling aluminum housing SAE pressure port 3 3000psi AXS4" = axial suction port 4 3000psi NBR sealing material MPT160/213 = with pump carrier and coupling for motor size 160 Pump carrier length 213 mm with claw coupling M = including engine, manufacturer Motive, Italy 160 = motor size L11 = motor power (kW) N4 = 4-pin B5 = motor with flange B5 IE3 = efficiency class IE3 400/690V-50Hz = operating voltage

You can find the current prices belongs to Settima - GR80 SMT 16B 1000L AXS4 coded product. You can ask all the codes and references except GR80 SMT 16B 1000L AXS4 too. All of the listed products are with guaranteed origin and high quality. You can find the most competitive prices about endustriel accessories in our company. We present you the most competative price and delivery time on GR80 SMT 16B 1000L AXS4 referenced product.

Where can I buy GR80 SMT 16B 1000L AXS4 by Settima in Italy?

You can purchase GR80 SMT 16B 1000L AXS4 by Settima from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the GR80 SMT 16B 1000L AXS4?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Settima in Italy?

While we are not the official distributor or seller of Settima in Italy, we source our products from reliable channels and offer you original Settima equipment at competitive prices.

How can I access GR80 SMT 16B 1000L AXS4 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for GR80 SMT 16B 1000L AXS4 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for GR80 SMT 16B 1000L AXS4?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
