Prices  GR45 SMT 16B 210L AC38/B5 RP T4  Settima  Italy

BRAND Settima
Product GR45 SMT 16B 210L AC38/B5 RP T4
Description Screw pump with motor
Internal code PRT4220752
Weight 11
Custom code 84136070
Technical specification MM132L7,5N4 B5IE3 230/400V-50Hz Q/P (1450 rpm; 46 mm²/s; 30 bar) =84.37L/min/6.66kW, npsh=2.37mWS Q/P (1450 rpm; 260mm²/s; 30bar) =87.71L/min/7.37kW, npsh=3.03mWS GR45 = size SMT 16B = pressure rating 40 bar 210L = nominal flow rate AC38/B5 = Direct mounting to electric motor assembly /B5 (ø300), the required feather key (DIN 6885 10x8x50 form A) is included Housing material aluminium RP = Externally adjustable pressure relief valve 5-25 bar SAE pressure connection 11/2 3000psi T4 = RP suction housing with SAE connector 2 3000psi, mounted in T4 Leakage connection mounted in D2 position (standard) Sealing material NBR MM = direct mounted engine, make Motive, Italy 132 = Engine size L7.5 = engine power (kW) N4 = 4-pin B5 = Motor with flange B5 IE3 = Efficiency class IE3 230/400V-50Hz = operating voltage

Settima - GR45 SMT 16B 210L AC38/B5 RP T4 referenced Screw pump with motor product produced by high technology.
GR45 SMT 16B 210L AC38/B5 RP T4 is the result of a far more developed technology compared to similar regular products. We are one of the few companies which can present an offer for this product. It produced result of tests of laborotory for years. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy GR45 SMT 16B 210L AC38/B5 RP T4 by Settima in Italy?

You can purchase GR45 SMT 16B 210L AC38/B5 RP T4 by Settima from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the GR45 SMT 16B 210L AC38/B5 RP T4?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Settima in Italy?

While we are not the official distributor or seller of Settima in Italy, we source our products from reliable channels and offer you original Settima equipment at competitive prices.

How can I access GR45 SMT 16B 210L AC38/B5 RP T4 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for GR45 SMT 16B 210L AC38/B5 RP T4 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for GR45 SMT 16B 210L AC38/B5 RP T4?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
