Prices G051.000102.010.009.010 GSR Italy

BRAND	GSR
Product	G051.000102.010.009.010
Description	Valve
Internal code	PRT4717957
Weight	1.2
Custom code	84818079
Technical specification	for connection to 24V DC Reference 051.000102 consists of: 051.000102 2/2 way solenoid valve Product name: C5121/1001/.182 Control type: servo-controlled, differential pressure min. 0.5 bar Construction: piston valve Function: NC - closed without power Connection: G1/4 Seat: 13.5 mm Pressure: 0.5 - 40 bar Temperature (medium): -10°C/+80°C Ambient temperature: -10°C/+35°C Viscosity (max.): 22 mm²/sec Material (housing): Brass 2.0402 Material (in contact with media): Brass 2.0401/stainless steel 1.4104 (AISI 430 F) Seal: NBR Installation: drive in horizontal or upright position B0051.000255 magnetic coil Type: .182 (K0511810) Voltage: 24V DC Dust/water protection: IP65 Power: 6.8W Duty cycle: 100% ED Connection type: DIN 43650-A ISO4400 device plug B0040.000047 Device plug 28 x 28 mm, in accordance with DIN 43650, unassembled in a plastic bag Cable screw connection: M20x1.5 connectable cables: Ø4.5-11mm max.1.5mm² Standard: EN 175301-803 Form A/ISO 4400 Voltage: 250V AC or DC Output: max 1.5A Ambient temperature: -40°C/+90°C Seal: NBR (black) - profile seal GDM 3-16 Galvanised steel screw

GSR - G051.000102.010.009.010 referenced Valve product produced by high technology.
You can ask all the codes and references except G051.000102.010.009.010 too. G051.000102.010.009.010 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. Make an offer to us for G051.000102.010.009.010 please contact us.

Where can I buy G051.000102.010.009.010 by GSR in Italy?

You can purchase G051.000102.010.009.010 by GSR from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the G051.000102.010.009.010?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of GSR in Italy?

While we are not the official distributor or seller of GSR in Italy, we source our products from reliable channels and offer you original GSR equipment at competitive prices.

How can I access G051.000102.010.009.010 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for G051.000102.010.009.010 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for G051.000102.010.009.010?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
