Prices G043.004640.090.099.090 GSR Italy

BRAND	GSR
Product	G043.004640.090.099.090
Description	2/2 way solenoid valve
Internal code	PRT4461778
Weight	0.8
Custom code	84818073
Technical specification	for connection to 230V 50-60HZ Reference E43230802.808XX consists of: 043.004640 2/2 way solenoid valve Item name: E4323/0802/.808 Control type: positively controlled, differential pressure at least 0 bar Construction: diaphragm valve Function: NC - closed without current Connection: G1/2 seat: 15 mm Pressure: 0 - 16 bar Temperature (medium): 0°C/+60°C Temperature (ambient): 0°C/+60°C viscosity (max.): 22 mm²/s Material (housing): stainless steel 1.4581 Material (touched by media): stainless steel 1.4104 Seal: FKM Installation: drive in an upright position Explosion protection: according to 2014/34/EU (ATEX) B0059.000176 solenoid Type: .808 (K0598090) Approval: PTB 10 ATEX 2013 X Throttle: Ex II 2G Ex e MB IIC T4 GB Dust: Ex II 2D Ex mb TB IIIC T130°C db Voltage: 230 V AC Power: 24W Necessary protection: 0.315A according to IEC 60127-2-1 Degree of protection: IP65 Connection type: terminal box Cable gland: M16 x 1.5 Cable clamping range: 6.5 - 9 mm duty cycle: 100% Ambient temperature: -55°C/+60°C Max. media temperature: +60°C

GSR - G043.004640.090.099.090 referenced 2/2 way solenoid valve product produced by high technology.
G043.004640.090.099.090 is the result of a far more developed technology compared to similar regular products. It distinguishes with price and quality among the similar products. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for G043.004640.090.099.090 GSR . G043.004640.090.099.090 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy G043.004640.090.099.090 by GSR in Italy?

You can purchase G043.004640.090.099.090 by GSR from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the G043.004640.090.099.090?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of GSR in Italy?

While we are not the official distributor or seller of GSR in Italy, we source our products from reliable channels and offer you original GSR equipment at competitive prices.

How can I access G043.004640.090.099.090 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for G043.004640.090.099.090 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for G043.004640.090.099.090?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
