Prices G040.001116.010.024.010 / B40261001.032XX GSR Italy

BRAND	GSR
Product	G040.001116.010.024.010 / B40261001.032XX
Internal code	PRT5120095
Weight	3.5
Custom code	84818079
Technical specification	for connection to 24V DC consists of: 040.001116 2/2 way solenoid valve Article description: B4026/1001/.032 Control type: servo-controlled, differential pressure min. 0.5 bar Construction: Diaphragm valve Function: NC - closed without current Connection: 5/4" cyl. IG according to ISO 228/1 Seat: 32.0 mm Pressure: 0.5 - 16 bar Temperature (medium): -10°C/+80°C Temperature (ambient): -10°C/+35°C Viscosity (max): 22 mm²/s Material (housing): 2.0402 brass Material (in contact with media): 2.0401 brass/ 1.4104 stainless steel Seal: NBR (Perbunan) Installation position: arbitrary, preferably with a standing magnet Note: with adjustable damping as standard B0051.000122 magnetic coil Type: .032 (K0510310) Voltage: 24V DC Dust/water protection: IP65 Power: 11 watts Duty time: 100% ED Connection type: device plug in accordance with DIN 43650-A ISO4400 B0040.000191 Device plug with LED (yellow) and diode protection circuit Operating voltage: 24V DC max operating current: 8A Ambient temperature: -40°C/+90°C Cable fitting: M16x1.5 connectable cables: Ø4.5-10mm max.1.5mm²

GSR - G040.001116.010.024.010 / B40261001.032XX referenced product produced by high technology.
You can provide the all references you look for in endustrial accessories in our company with our unique product range. G040.001116.010.024.010 / B40261001.032XX referenced product which is satisfy the customer's needs, offers advantages of quality and cost. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for G040.001116.010.024.010 / B40261001.032XX GSR . Contact us if you are looking for alternative price of G040.001116.010.024.010 / B40261001.032XX .

Where can I buy G040.001116.010.024.010 / B40261001.032XX by GSR in Italy?

You can purchase G040.001116.010.024.010 / B40261001.032XX by GSR from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the G040.001116.010.024.010 / B40261001.032XX?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of GSR in Italy?

While we are not the official distributor or seller of GSR in Italy, we source our products from reliable channels and offer you original GSR equipment at competitive prices.

How can I access G040.001116.010.024.010 / B40261001.032XX catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for G040.001116.010.024.010 / B40261001.032XX on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for G040.001116.010.024.010 / B40261001.032XX?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
