| BRAND | Black Box |
| Product | EVNSL0172YL-0007 |
| Internal code | PRT4265255 |
| Technical specification | CAT5E SHLD PATCH CABLE 7' 26 AWG STRND CM Yellow EVNSL0172xx-xxxx xx = Color (BL=BLUE, GN=GREEN, RD=RED, YL=YELLOW, WH=WHITE, GY=GRAY, BR=BROWN, BK=BLACK, VI=VIOLET and OR=ORANGE) FUNCTIONAL NOTES: This is Category 5e foil shielded, stranded PVC Bulk Cable This bulk cable can be used in specialized applications that require the flexibility of making custom CAT 5e shielded stranded assemblies This Category 5e bulk cable is made with an overall foil wrap shield around 4 stranded pairs. It is recommend to use with a Shielded CAT 5e PLUG PACKAGE INCLUDES: 1 Reel PHYSICAL SPECIFICATIONS: Color = BLUE, GREEN, RED, YELLOW, WHITE, GRAY, BROWN, BLACK, VIOLET and ORANGE) Jacket = PVC (CM) Cable Core = Stranded Copper Wire Gauge for = 26 AWG Cable OD = 0.220 (5.6 mm) Shielding = Foil Tape Insulation Material = HDPE Drain Wire = Tinned Copper Jacket Material = PVC ELECTRICAL SPECIFICATIONS: MHZ Rating = 100 MHZ Rating Temperature Voltage = 60 C Conductor Resistance = 14.07 Ohm / 100m 20 C MAX Characteristic Impedance = 1-100 MHz, 100+- 15 ohms Resistance Un-Balanced = MAX 5% Capacitance Un-Balanced = MAX330 pF / 100m Mutual Capacitance = MAX 5600 pF / 100m Attenuation (@100 Mhz) = 33.0 dB NEXT (@ 100 Mhz) = 35.0 dB PS-NEXT (@ 100 Mhz) = 32.0 dB |
