| BRAND | Eltra Encoder |
| Product | EH30M500Z5P6X3PR3 |
| Internal code | PRT5068883 |
| Weight | 0.05 |
| Technical specification | Resolution from 50 to 1024 ppr Power supply1 5 = 4,5 ... 5,5 V DC 5/30 = 4,5 ... 30 V DC (reverse polarity protection) Current consumption without load 100 mA max Max load current C / P = 50 mA / channel L = 20 mA / channel Electrical interface2 NPN open collector (AEIC-7273, pull-up max +30 V DC) push-pull / line driver HTL (AEIC-7272 or similar) line driver RS-422 (AELT-5000 or similar) Max output frequency 105 kHz Counting direction A leads B clockwise (shaft view) Index signal 90°e (gated A&B) Mean time to dangerous failure (MTTFd)3 according to EN ISO 13849-1 244 years Mission time (Tm)3 20 years Diagnostic coverage (DC)3 0% Cable type shielded - fixed installation conductors section 0,22 mm2 / AWG 24 bending radius min 60 mm Electromagnetic compatibility according to 2014/30/EU directive RoHS according to 2011/65/EU directive UL / CSA file n. E212495 Bore diameter ø 6 / 6,35 (1/4”) mm Enclosure rating IEC 60529 mod. 17 IP 40 mod. 30 IP 40 or 54* Max rotation speed 6000 rpm limited by output frequency Shock 50 G, 11 ms (IEC 60068-2-27) Vibration 10 G, 10 ... 2000 Hz (IEC 60068-2-6) Moment of inertia 0,5 x 10-6 kgm2 (12 x 10-6 lbft2) Flange material (mod. 17) aluminium Hub material aluminium Cover material PA66 / PA6 glass fiber reinforced Shaft radial play allowed ± 0,04 mm Shaft axial play allowed ± 0,1 mm Operating temperature4, 5 -20° ... +85°C (-4° ... +185°F) Storage temperature5 -25° ... +85°C (-13° ... +185°F) |
Where can I buy EH30M500Z5P6X3PR3 by Eltra Encoder in Italy?
You can purchase EH30M500Z5P6X3PR3 by Eltra Encoder from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.
What is the price of the EH30M500Z5P6X3PR3?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Eltra Encoder in Italy?
While we are not the official distributor or seller of Eltra Encoder in Italy, we source our products from reliable channels and offer you original Eltra Encoder equipment at competitive prices.
How can I access EH30M500Z5P6X3PR3 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for EH30M500Z5P6X3PR3 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for EH30M500Z5P6X3PR3?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
