Prices DRB14 Erhardt Leimer Italy

BRAND	Erhardt Leimer
Product	DRB14
Description	belt guide system
Internal code	PRT4740246
Weight	12
Custom code	84798997
Technical specification	ELGUIDER EL.NET belt guide system with DR 14 rotation.. as a compact version to drive a running network With the following configuration: E+L System: DRB1402 DR - type series: DR 1401 Construction dimensions: size 1/predecessors DR 1275 Standard execution variant Steering system: edge guidance Nominal width NB: 250 mm LUE transfer range: 180 mm Roll diameter: 40 mm Roller surface - INLET: ALUMINIUM Roller surface - outlet: Al- with rubber cork Sensor: FX 46 ultrasonic sensor Sensor support beam: manually, w/ or fine adjustment Sensor position indicator: without Fieldbus interface: standard: UDP Operating voltage: 24V DC - 4.5A Note: power not included Operator panel: RT 4008 touch screen Plug type: straight Cable, power supply: 5 m, 4P-M12L-FS/-- Cable, digital input/output: 5 m, 8P-M12A-MS/- Cable, Ethernet External connection: without Cable, Ethernet E+L connection: 5 m, 4P-M8D-MS/M8D-MS Junction table: without Mounting: 13-E1-A1-A-RL Mounting: with groove Tread cleaning: yes Max. correction distance: 38 mm Maximum belt tension: 300 N Painting: RAL 7021 gray black Dimensional drawing: DRB14__-158890M

You can find the current prices belongs to Erhardt Leimer - DRB14 coded belt guide system product. DRB14 became irreplaceable of foundations. All of the listed products are with guaranteed origin and high quality. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy DRB14 by Erhardt Leimer in Italy?

You can purchase DRB14 by Erhardt Leimer from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the DRB14?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Erhardt Leimer in Italy?

While we are not the official distributor or seller of Erhardt Leimer in Italy, we source our products from reliable channels and offer you original Erhardt Leimer equipment at competitive prices.

How can I access DRB14 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for DRB14 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for DRB14?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
