| BRAND | Interroll |
| Product | DM 0113 |
| Internal code | PRT4726907 |
| Weight | 53.47 |
| Technical specification | MI-DM0113 DM1133-AAA03B0E8FJD-607mm Product name DM 0113 Asynchronous 3-phase Degree of protection IP 69K Tube length (SL) 600.0 mm Drum width (FW) 607.0 mm Installation length (EL/LW/BF) 620.0 mm Overall axle length (AGL) 670.0 mm Power 225 W Number of pins 2 windings Torque [Nm] 14.0 Belt pull force 247 N Gear ratio (i) 20.00 Transmission Material name Cast-Iron: GGG-40 Speed at frequency 1 0.82 m/s Frequency 1 50 Hz external connection diagram M34 high voltage 400 V low voltage 230 V Rated current, high voltage 0.56 A rated current, low voltage 0.96 A Speed at frequency 2 0.98 m/s Frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Steel pipe material: St37-2/AISI 1015 Tube diameter (A) 113.5 mm Tube diameter (B) 112.0 mm Spherical tube shape (standard) Cover A standard version Cover B version Standard Cover A Material ALU: EN-AC43400/AL239 Cover B Material ALUMINUM: EN-AC43400/AL239 Shaft A version standard Ø25mm shaft B version standard Ø25mm Shaft A material stainless steel: 1.4305/303 Shaft B material stainless steel: 1.4305/303 Wave A wrench surface width (F) 20.0 mm Wave B wrench surface width (F) 20.0 mm Wave A wrench surface length (C) 25.0 mm Wave B wrench surface length (C) 25.0 mm Oil type synthetic food oil Electrical connection straight screw connection Elek. Connection material brass CuZn39Pb3/MS58 Power cable length 5.0 m Power cable type unshielded; not halogen-free |
Where can I buy DM 0113 by Interroll in Italy?
You can purchase DM 0113 by Interroll from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.
What is the price of the DM 0113?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Interroll in Italy?
While we are not the official distributor or seller of Interroll in Italy, we source our products from reliable channels and offer you original Interroll equipment at competitive prices.
How can I access DM 0113 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for DM 0113 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for DM 0113?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
