Prices DMP 331P Bd Sensors Italy

BRAND	Bd Sensors
Product	DMP 331P
Description	Industrial Pressure Transmitter
Internal code	PRT3389126
Weight	0.2
Technical specification	Code: 500-2501-1-3-100-Z00-1-1-2-000 Device type: DMP 331P Measurement variable: relative Input code: 0... 2.5 bar El. Output: 4... 20 mA/2-wire Supply: 8... 32 VDC Accuracy: 0.35% FSO IEC Supply +: 1 Supply -: 2 Screen: Grounding Protection class: IP65 Mech Connection: G 1/2" flush with the front, DIN 3852 Separating membrane: stainless steel 1.4435 (316L) Seal: FKM Filling liquid: Food-grade oil Special design: Standard membrane position: membrane downwards Calibration temperature: 20 °C Type plate: BDS GmbH Type plate - Position: Standard El. Connection: plug and cable socket ISO 4400

You can find the current prices belongs to Bd Sensors - DMP 331P coded Industrial Pressure Transmitter product. You can ask all the codes and references except DMP 331P too. All of the listed products are with guaranteed origin and high quality. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. We present you the most competative price and delivery time on DMP 331P referenced product.
