Prices DKZ 110 Warex Italy

BRAND	Warex
Product	DKZ 110
Description	butterfly valve
Internal code	PRT4174157
Weight	63
Custom code	84818085
Technical specification	for medium : air chemical not aggressive, not sticky working pressure : 1,0 bar max. allowable working pressure : 1,0 bar (Ps) MAWP (Note: MAWP = design pressure) max. allowable working temperature: 0° C to + 120° C (Ts) MAWT ambient temp.: 0° C to +50° C (Ta) Ex-protection : not required Rating of butterfly-valves according PED/2014/68/EU, diagram 7 Certified module A2 The butterfly-valves are not subject to this conformity assessment Warex-butterfly valve, type: DKZ 110 for mounting between flanges, drilled in ANSI 150 lbs body of silumin sealing element of EPDM black replaceable disc of stainless steel 1.4408 for DN 50...350, otherwise 1.4301 shaft of stainless steel 1.4057 or equivalent shaft sealing with O-rings bearing bush of brass all screws of stainless steel test pressure: design pressure x 1,1 bar for tightness 5129a DN 400 face to face: 67 mm WH81 mounted wormgear, type WH 81/AB232-13 1000 Nm / incl. handwheel

Warex - DKZ 110 referenced butterfly valve product produced by high technology.
DKZ 110 is the result of a far more developed technology compared to similar regular products. All of the listed products are with guaranteed origin and high quality. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. We present you the most competative price and delivery time on DKZ 110 referenced product.

Where can I buy DKZ 110 by Warex in Italy?

You can purchase DKZ 110 by Warex from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the DKZ 110?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Warex in Italy?

While we are not the official distributor or seller of Warex in Italy, we source our products from reliable channels and offer you original Warex equipment at competitive prices.

How can I access DKZ 110 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for DKZ 110 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for DKZ 110?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
