Prices  Type DKD110 DN 200 / WX2000  Warex  Italy

for medium: powder paint
Property: free-flowing, chemically neutral,
not tending to bake
Work pressure: pressureless
max. allowable
Operating overpressure: pressureless (Ps) MAWP
(Note: MAWP = Ausl. -Pressure)
Operating temperature: 0 °C... + 60 °C (Ts) MAWT
Surround. -Temperature: 0 °C... + 50 °C (Ta)
Explosion protection: II 1/3 D Ex h IIIC T85°C Da/Dc X
evaluation of butterfly valves in accordance with DGRL 2014/68/EU,
Diagram 7, certified module A2.
The valves are not subject to conformity assessment.
Test pressure: close-tight, not pressure-tight

Butterfly valve, type DKD110 DN 200
Construction length 54 mm
for clamping between flanges in accordance with EN 1092, PN 10
metallic sealing - sealing
not pressure-tight in the passageway!!
Leakage 1-2% area equivalent
1.4408 stainless steel housing with grounding connection
Stainless steel flap plate 1.4408 grounded - polished Ra < 0.8 μm -
Perfectly fitted into the housing
1.4057 or higher grade stainless steel shafts
Brass shaft bearing - socket
Shaft sealing with O-rings
The valve is equipped with the following special equipment:
Pressure-shock-resistant housing: 10.0 bar
- Housing polished on the inside Ra < 0.3 -
------------------------------------------------------
- Internal housing Ø 199.1 mm -
------------------------------------------------------
- Flap disc Ø 197 mm -
------------------------------------------------------
further attachments:
pneumatic rotary actuator
AT 150 DR double-acting
required control pressure 6.0 bar
