Prices CFIB - 4 - MA - 35H - ET- 0- 0 C.E. srl Italy

BRAND	C.E. srl
Product	CFIB - 4 - MA - 35H - ET- 0- 0
Description	GLOBTOP case
Internal code	PRT4745910
Weight	1.8
Technical specification	GLOBTOP CF series case mod. CFIB in aluminum alloy (copper≤ 0.1%), with open/closed position indicator for rotary valves ATEX Certification (BVI 19 ATEX 0006): Ex II 2 GD — Ex db IIC T6/T5/T4 Ex tb IIIC T85/T100/T135°C (Tamb. from -50°C to +60/+80/+100°C) - Cable entry: 3 3/4 “npt-f holes - Terminal block: 12 clamps plus ground connection (option 12 clamps) - Degree of protection: IP66/67/67M (with shaft rotation test) - Surface treatment: chromating (in accordance with MIL5541 Class 1A) + polyester coating (RAL7000) (maximum resistance to chemicals and atmospheric agents) - Position indicator: red-green three-dimensional dome - Shaft: namur coupling - 316 stainless steel material Each case is equipped with number 4 (2AP+2CH) GO SWITCH (TOPWORX) with the following characteristics: - Series 30 Mod. 35 Hermetic passive magnetic stroke finer (without power supply and without Reed contacts) - mechanical contact (snap action & dry contact): gold-plated SPDT in silver-cadmium; airtight - contact flow: 4A AC 120V AC, 2A AC 240V AC and 3A DC 24V DC resistive load - sensitive distance: 3 mm. (with iron feedback) - differential (hysteresis): 3 mm. (with iron feedback) - response time: 8 milliseconds - working temperature: see T.amb. for custody certification - shell: cupronickel - nr.4 insulated PVC 105°C connection wires

You can find the current prices belongs to C.E. srl - CFIB - 4 - MA - 35H - ET- 0- 0 coded GLOBTOP case product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. All of the listed products are with guaranteed origin and high quality. Our company can make an offer even if we do not distributor of Italy. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy CFIB - 4 - MA - 35H - ET- 0- 0 by C.E. srl in Italy?

You can purchase CFIB - 4 - MA - 35H - ET- 0- 0 by C.E. srl from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the CFIB - 4 - MA - 35H - ET- 0- 0?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of C.E. srl in Italy?

While we are not the official distributor or seller of C.E. srl in Italy, we source our products from reliable channels and offer you original C.E. srl equipment at competitive prices.

How can I access CFIB - 4 - MA - 35H - ET- 0- 0 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for CFIB - 4 - MA - 35H - ET- 0- 0 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for CFIB - 4 - MA - 35H - ET- 0- 0?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
