Prices CFIB–1–MA–35H–ET–0-0 C.E. srl Italy

BRAND	C.E. srl
Product	CFIB–1–MA–35H–ET–0-0
Description	Case
Internal code	PRT4801382
Weight	1.57
Custom code	90330000
Technical specification	GLOBTOP CF series mod. CFIB in aluminum alloy (copper≤ 0.1%), with open/closed position indicator for rotary valves ATEX certification (BVI 19 ATEX 0006): Ex II 2 GD — Ex db IIC T6/T5/T4 Ex tb IIIC T85/T100/T135°C (Also from -50°C to +60/+80/+100°C) - Cable input: n.3 3/4 “npt-f holes - Terminal block: 3 terminals plus ground connection (option 12 terminals) - Degree of protection: IP66/67/67M (with shaft rotation test) - Surface treatment: chrome plating (in accordance with MIL5541 Class 1A) + polyester coating (RAL7000) (maximum resistance to chemical and atmospheric agents) - Position indicator: three-dimensional dome color red-green - Shaft: namur coupling - 316 stainless steel material Each case is equipped with no. 1 GO SWITCH (TOPWORX) with the following characteristics: - Passive Hermetic Series 30 Mod. 35 magnetic stopper (without power supply and without reed contacts) - mechanical contact (snap action & dry contact): gold-plated SPDT in silver-cadmium; hermetic - contact range: 4A AC to 120V AC, 2A AC to 240V AC and 3A DC 24V DC resistive load - Sensitive distance: 3 mm. (with ferrous feedback) - differential (hysteresis): 3 mm. (with ferrous feedback) - response time: 8 milliseconds - working temperature: see T.amb. of case certification - shell: cupronickel - nr.4 PVC-insulated connection conductors 105°C

You can find the current prices belongs to C.E. srl - CFIB–1–MA–35H–ET–0-0 coded Case product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. It distinguishes with price and quality among the similar products. Our company can make an offer even if we do not distributor of Italy. Make an offer to us for CFIB–1–MA–35H–ET–0-0 please contact us.

Where can I buy CFIB–1–MA–35H–ET–0-0 by C.E. srl in Italy?

You can purchase CFIB–1–MA–35H–ET–0-0 by C.E. srl from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the CFIB–1–MA–35H–ET–0-0?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of C.E. srl in Italy?

While we are not the official distributor or seller of C.E. srl in Italy, we source our products from reliable channels and offer you original C.E. srl equipment at competitive prices.

How can I access CFIB–1–MA–35H–ET–0-0 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for CFIB–1–MA–35H–ET–0-0 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for CFIB–1–MA–35H–ET–0-0?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
