| BRAND | HIMMEL |
| Product | CAF10-G56S4U / 2010000132 |
| Description | worm gear motor |
| Internal code | PRT4940028 |
| Weight | 12 |
| Custom code | 85015100 |
| Technical specification | 6-pin arting plug with mating plug Dimension sheet: CAF14/600036 Gearbox design/Type: HIMMEL® worm gear motor/HIMMEL® -worm gear motor Transmission Type/Type: CAF10-G56S4U Dimension sheet: CAF14/600036 Output speed/ Output speed [1/min; rpm]: 3.00//3.60 Translation/Ratio [i]: 463.65 Color/colour: RAL 9006 white aluminium/White aluminium Corrosivity category/corrosion protection: C1: i.a.A. DIN EN ISO 12944-2/HN716.21 Paint layer thickness [μm]: 60-80 Protection class: IP55 Design/mounting position: H-05-A Output torque/ Output torque [Nm]: 56//56 Direction of rotation: right/right [CW] Output shaft gearbox/ Output shaft [mm; inch]: H20x124.50 Gearbox bearing: assigned bearings Oil type: CLP PG 460 Synth.oil Oil quantity [l]: 0.22 Flange diameter/Flange diameter [mm; inch]: A140 Shaft material/Shaft material: C45 Gearbox sealing/Sealing: shaft seal ring (WDR)/shaft seal ring Label/Approval|Identification/Certification: CE Number of poles/poles: 4 Rated frequency/ Nominal frequency [Hz]: 50//60 Rated voltage/nominal voltage [V]: 220-240/380-420//254-277/440-480 Circuit/ Wiring: S100//S100 (D/Y//D/Y) Rated power/nominal power [kW]: 0.06//0.072 Rated motor speed/Motor speed nom. [1/min; rpm]: 1380//1680 Rated current/Nominal current In [A]: 0.42/0.24//0.43/0.25 CosPhi/CosPHI: 0.68 KK location/Terminal box position: 3D KK version/Terminal box type: plastic one-piece angled with harting plug/ plastic-monobloc-slope with Harting connector Winding protection/Motor protector: ohne/without Motor output shaft/Output shaft [mm; inch]: V11x24.5 Sealing motor/Sealing motor: normal/normal Insulation class: F Operating mode/Duty type: S1 Fan/Fan: without/non-ventilated |
Where can I buy CAF10-G56S4U / 2010000132 by HIMMEL in Italy?
You can purchase CAF10-G56S4U / 2010000132 by HIMMEL from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.
What is the price of the CAF10-G56S4U / 2010000132?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of HIMMEL in Italy?
While we are not the official distributor or seller of HIMMEL in Italy, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.
How can I access CAF10-G56S4U / 2010000132 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for CAF10-G56S4U / 2010000132 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for CAF10-G56S4U / 2010000132?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
