Prices C21-M1C4 HIMMEL technologies Italy

BRAND	HIMMEL technologies
Product	C21-M1C4
Description	GEARMOTOR
Internal code	PRT3800306
Weight	20
Custom code	85015100
Technical specification	Maßblatt: C04 Getriebebauart / Type: HIMMEL®-Schneckengetriebemotor / HIMMEL®-worm gear Getriebetyp / Type: C21-M1C4 Maßbild / Dimension sheet: C04 Abtriebsdrehzahl / Output speed [1/min; 1/rpm]: 13.10 Übersetzung / Ratio [i]: 127.94 Farbe / colour: RAL 5015 Himmelblau 2K / Sky blue 2K-PUR Schutzart / protection class: IP54 Bauform / mounting position: B8-00-AB Abtriebsmoment / Output torque [Nm]: 171.0 Drehrichtung Abtrieb/Output direction of rotation: rechts / right Abtriebswelle Getriebe / Output shaft [mm; Zoll]: V25x50 2. Wellenende Getriebe / 2.Output shaft [mm; Zoll]: V25x50 Lagerung Getriebe / Bearing: zugeordnete Lagerung / assigned bearings Ölart / Oil type: CLP PG 460 Synth.oil Ölmenge / Oil quantity [l]: 0.70 Wellenwerkstoff / Shaft material: C45 Abdichtung Getriebe / Sealing: Wellendichtring (WDR) / shaft seal ring Elektrische Ausführung / Elektrical design: CE Polzahl / Poles: 4 Nennfrequenz / Nominal frequency [Hz]: 60 Nennspannung / Nominalvoltage [V]: 254-277/440-480 Schaltung / Wiring: S100 (D/Y) Nennleistung / Nominalpower [kW]: 0.37 Motordrehzahl nenn / Motor speed nom. [1/rpm]: 1670 Nennstrom / Nominal current In [A]: 1.55/0.90 KK-Lage / Terminal box position: 1A KK-Ausführung / Terminal box type: Kunststoff / plastic Wicklungsschutz / Motor protector: ohne / without Abtriebswelle Motor / Output shaft [mm; Zoll]: V10x16.5 Abdichtung Motor / Sealing motor: normal / normal Isolationsklasse / Insulation class: F Betriebsart / Duty type: S1 Lüfter / Fan: Kunststoff / plastic

HIMMEL technologies - C21-M1C4 referenced GEARMOTOR product produced by high technology.
C21-M1C4 became irreplaceable of foundations. C21-M1C4 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. We present you the most competative price and delivery time on C21-M1C4 referenced product.

Where can I buy C21-M1C4 by HIMMEL technologies in Italy?

You can purchase C21-M1C4 by HIMMEL technologies from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the C21-M1C4?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of HIMMEL technologies in Italy?

While we are not the official distributor or seller of HIMMEL technologies in Italy, we source our products from reliable channels and offer you original HIMMEL technologies equipment at competitive prices.

How can I access C21-M1C4 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for C21-M1C4 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for C21-M1C4?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
