| BRAND | Cemb |
| Product | C206 |
| Description | WHEEL BALANCER |
| Internal code | PRT3762427 |
| Weight | 190 |
| Technical specification | 7506088 Manufacturer no. 900C206B2 Mobile including flange package • Mobile, hand-driven for LLkW, truck, bus and car wheels • Manual wheel data entry via keyboard • wheel drive for heavy wheels by hand crank via mechanical transmission • wheel centering using spindle • Measuring speed less than 100 rpm, so no wheel cover required • ALU-M program for automatic positioning of adhesive weights in the rim bowl • optimization and split program for backspoke placement • 12/24 volt external power supply possible ** In package included: • 4- and 5-arm star • mounting flange • 5 centering bolts • 5 nuts • Spacer G40 - 3 cones (43-69, 60-81, 79-110) • LLKW cone (97-170) • clamping nut • tensioning hood • rim width gauge rim diameter 10 - 26.5 inch rim width inch 1.5 - 20 max. wheel diameter mm 1300 max. wheel weight kg 250 Measurement time s 8 - 20 connection V/Hz 115/230 - 50/60 Shaft diameter 40 mm space requirements L x W mm 875 x 1210 |
