Prices  BC211UA23-1NW  Union Special  Italy

REGISTRATION NUMBER: 84522900000 heavy duty two-thread double chain stitch sack Automatic sewing machine with new vertically acting pusher foot system and parts protected from rust. For sealing filled bags and bags made of paper and plastic film (minimum thickness of 0.18 mm film) or at the same time stitching on a Crepe paper ribbon with a width of 50 - 70 mm (please specify in the order). Optionally also Can be closed with an easy-open band. Guides for sealing cords to seal the needle punctures. Rust-proof Equipped with new “fast” pneumatic operated guillotine thread chain separator or - Rider tape cutter close behind the housing, but without equestrian ligament apparatus. Vertically acting pusher foot system. Compressed air required: 3 - 4 bar. For use with the combined bag delivery and circumcision device. Band overhang front and rear approx. 40-45 mm with additional initial cutting impulse. Built-in pressure lubrication. Housing in closed shell design with external large oil filter. Low vibration and noise With wide, specially rust-protected seams as a result, better transport. Start-stop controlled by photocell. Thread chain and ribbon cutter automatically, by pneumatically operated guillotine (without button, without magnetic valve and without proximity switch). stitch length: 6.5 - 12.5 mm, Default setting 9 mm Stitch type Two-thread double chain stitch 401 up to max. 2750 rpm, depending of sewing material and process Passage under strip cutter: up to 12.7 mm Maximum seam thickness for paper bags: 32 layers, depending on the weight of the paper
