Prices  BBF/KSF (N9) DN150/6 Böhmer Italy

BRAND Böhmer
Product BBF/KSF (N9) DN150/6
Description Underground Ball valve
Internal code PRT4224078
Technical specification Nominal pressure PN100 Line Size, Wall Thickness, mm Ø159х6 Pipe material 20в Operating Temperature, 0C 0 ÷ +50 Operating pressure, MPa(g) 7,5 Max. Valve differential pressure, MPa(g) 7,5 Valve Operator Type - Gas-over-oil actuator Installation - Underground horizontal End Connections - Welding (EN 1092-1 / ASME B16.5) Fire safe ISO 10497 / BS 6755-2 / API 607 Applicable Standard or Specifications API 6D / ISO 14313 / EN ISO 17292 / 97/23/EC / ASME VIII-2 Leakage Class - Zero Leakage Face-to-face and end-to-end dimensions - API 6D / EN 558-1 / ASME B16.10 Process in - Natural gas Port (Regular or Full) - Full bore Valve operating position - Open Valve failure position - Close Stroke time, sec. - 30 Stem extension (from the axis of the pipeline) - L=2200 mm

You can find the current prices belongs to Böhmer - BBF/KSF (N9) DN150/6 coded Underground Ball valve product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. All of the listed products are with guaranteed origin and high quality. Our company can make an offer even if we do not distributor of Italy. BBF/KSF (N9) DN150/6 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.
