Prices p/n: B78120014, Type: CTUB101-CTBC60 Bender Italy

BRAND	Bender
Product	p/n: B78120014, Type: CTUB101-CTBC60
Description	current transformer
Internal code	PRT4123451
Weight	0.53
Custom code	90303370
Technical specification	LV current transformer Primary current 250 A Line feed-through diameter:60 mm Rated voltage: 800 V Over voltage category III Operating height: ≤ 2000 m above sea level Rated surge voltage: IC1/IC2 8 kV Rated insulation voltage (reinforced insulation): IC1/IC2 800 V. Pollution level: 2 Supply voltage US: DC ±12 V. Us Workspace: ±2% Ripple US: ≤ 1% Own consumption: ≤ 2.5 W Inrush current 500 mA (referred to the RCMA423) CTBC60 at IΔn = 30 mA: 160 A. CTBC60 at IΔn = 300 mA: 250 A. Measuring accuracy ± 1 % Test development: Yes Thermal rated continuous differential current Icth: 30 A. Thermal rated short-time current Ith: 2.4 kA/1 s. Rated surge current Idyn: 6 kA/40 ms Output Name: S1 (k), S2 (l) Scaling 400 mV/1 A. Max. voltage 10 V Max. Connection length 10 m Output resistance 172 Ω Protection class, installation (DIN EN 60529): IP40 Protection class, terminals (DIN EN 60529): IP20 Flammability class UL94 V-0

Bender - p/n: B78120014, Type: CTUB101-CTBC60 referenced current transformer product produced by high technology.
p/n: B78120014, Type: CTUB101-CTBC60 became irreplaceable of foundations. It distinguishes with price and quality among the similar products. You can find the most competitive prices about endustriel accessories in our company. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy p/n: B78120014, Type: CTUB101-CTBC60 by Bender in Italy?

You can purchase p/n: B78120014, Type: CTUB101-CTBC60 by Bender from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the p/n: B78120014, Type: CTUB101-CTBC60?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Bender in Italy?

While we are not the official distributor or seller of Bender in Italy, we source our products from reliable channels and offer you original Bender equipment at competitive prices.

How can I access p/n: B78120014, Type: CTUB101-CTBC60 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for p/n: B78120014, Type: CTUB101-CTBC60 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for p/n: B78120014, Type: CTUB101-CTBC60?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
