Prices G043.003863.090.099.090 / B43281002.242X2 GSR Italy

BRAND	GSR
Product	G043.003863.090.099.090 / B43281002.242X2
Internal code	PRT5087357
Weight	10
Custom code	84818059
Technical specification	for connection to 230V 50-60HZ consists of: 043.003863 2/2 way solenoid valve Article description: B4328/1002/.242-X2-MH Control type: force-controlled, differential pressure min.0 bar Construction: Diaphragm valve Function: NC - closed without current Connection: G2 Seat: 50mm Pressure: 0 - 16 bar Temperature (medium): 0°C/+80°C Temperature (ambient): 0°C/+35°C Viscosity (max.): 22 mm²/sec Material (housing): 2.0402 brass Material (in contact with media): 2.0401 brass/ 1.4104 stainless steel Seal: FKM Installation: drive in an upright position Option: X2 = 2x limit switch; closer; IP65; top, .: Down (open/close) (arrangement: 16) .: MH = valve with manual operation and suitable for lying .: Installation B0051.000339 magnetic coil Type: .242 (K0512490) Voltage: 230V 50-60HZ Power: 46 watts Protection class: IP65 Duty time: 100% ED Connection type: terminal box with M16x1.5 cable screw Cable clamp range: Ø5-10mm

GSR - G043.003863.090.099.090 / B43281002.242X2 referenced product produced by high technology.
G043.003863.090.099.090 / B43281002.242X2 became irreplaceable of foundations. We are one of the few companies which can present an offer for this product. You can find the most competitive prices about endustriel accessories in our company. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy G043.003863.090.099.090 / B43281002.242X2 by GSR in Italy?

You can purchase G043.003863.090.099.090 / B43281002.242X2 by GSR from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the G043.003863.090.099.090 / B43281002.242X2?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of GSR in Italy?

While we are not the official distributor or seller of GSR in Italy, we source our products from reliable channels and offer you original GSR equipment at competitive prices.

How can I access G043.003863.090.099.090 / B43281002.242X2 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for G043.003863.090.099.090 / B43281002.242X2 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for G043.003863.090.099.090 / B43281002.242X2?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
