Prices ATMOS V2-KR Baratti Italy

BRAND	Baratti
Product	ATMOS V2-KR
Description	Complete pump
Internal code	PRT4206922
Weight	480
Custom code	84141025
Technical specification	ATMOS V2-KR Var.0102 Roots Blower Vacuum Absolutely oil- and wear-free compaction - Labyrinth waterproofing to the compressor room with relief hole - air-cooled, belt drive with belt protection - two-stage exhaust silencer - Includes vacuum limiting valve - Includes suction side paper fine filter - including glycerol-filled tube pressure gauge D= 63mm (-1 to 0 bar) Technical data in general: Intake volume: 50 to 420m3/h (15 to 75Hz) Vacuum (continuous): 300mbar ABS Ultimate vacuum (intermeting): 100mbar abs. Fan speed: 800 to 4500min -1 (15 to 75Hz) Vacuum Limiting Valve Size: 1 Fine filter on the suction side connection thread: R 2 1/2 “” Exhaust outlet outer diameter: 76.1mm Noise level (speed/pressure dependent) approx.: 74 dB (A) dB (A) (according to free field measurement DIN 45635) For dimensions see dimension sheet no.: 900087AA Technical data for your application: Suction volume: 270 m³/h delta p ፦500 mbar Safety valve set to፦ 500 mbar Fan speed: 2979 rpm Motor: special voltage 7.5 kW, 3 x 400V, 50Hz, 2950 rpm IE3, B5, IP55, KKL, ISO class F, 3 x bimetal KRS engine: SPA 132-2r, TL 2012, 38mm KRS blower: SPA 132-2r, TL 2012, 40mm V-belt: XPA 1282 (2 pieces) Serial No: PAINT: RAL 7035 Oil filling: Castrol Alphasyn EP220 DOCUMENTATION: German/English via pdf file

Baratti - ATMOS V2-KR referenced Complete pump product produced by high technology.
ATMOS V2-KR became irreplaceable of foundations. Our company supply ATMOS V2-KR referenced product fastest and securest on your request. You can find the most competitive prices about endustriel accessories in our company. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy ATMOS V2-KR by Baratti in Italy?

You can purchase ATMOS V2-KR by Baratti from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the ATMOS V2-KR?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Baratti in Italy?

While we are not the official distributor or seller of Baratti in Italy, we source our products from reliable channels and offer you original Baratti equipment at competitive prices.

How can I access ATMOS V2-KR catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for ATMOS V2-KR on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for ATMOS V2-KR?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
