Prices 100283507-014 ARI Italy

BRAND	ARI
Product	100283507-014
Internal code	PRT4519587
Weight	21
Technical specification	Figure 55,440 DN 25 ARI-STEVI 440 Straight type control valve with flanges 1.4408 DN 25 Nominal pressure: PN 40 Flange drilling: according to DIN PN40 Cone design: * parabolic cone Leakage class IV S1 Kvs value: 10 Characteristic curve: equal percent Execution: * Oxygen version Oil-free and grease-free for oxygen Spindle seal: * PTFE packing with BAM approval max. 60°C Final acceptance test: APZ EN10204 3.1 Acceptance material testing: APZ EN10204 3.1 Drive: DP32 Complementary product description: * HP max. 14 bar TS max. 30°C Effectively (b.pneum.antr): Spring closes in case of air failure feathery. (bar) /stroke (mm): 1.50-2.90 stroke 20 mm Erford. Setting pressure (bar): 3.2 bar max. admissible Setting pressure (bar): 6 max. closing pressure (bar): * 14 Distance column length: L1=188 mm Distance column spacing: 100 mm Coupling: M10 thread Positioner: EPS 33 Input signal: 4 - 20mA 2-wire Adjusted: 4 mA valve closed Inlet with ventilation air (bar): 6 bar

You can find the current prices belongs to ARI - 100283507-014 coded product. 100283507-014 became irreplaceable of foundations. All of the listed products are with guaranteed origin and high quality. It produced result of tests of laborotory for years. Make an offer to us for 100283507-014 please contact us.

Where can I buy 100283507-014 by ARI in Italy?

You can purchase 100283507-014 by ARI from Partelli SRL. We serve customers across Italy, offering competitive prices and reliable service.

What is the price of the 100283507-014?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of ARI in Italy?

While we are not the official distributor or seller of ARI in Italy, we source our products from reliable channels and offer you original ARI equipment at competitive prices.

How can I access 100283507-014 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 100283507-014 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 100283507-014?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
