| BRAND | Ephy Mess |
| Product | 994210409000001 |
| Description | Temperature sensor |
| Internal code | PRT4253136 |
| Custom code | 90259000 |
| Technical specification | Temperature sensor, D72000365 2Pt100, 2 conductor circuit Class B ±0.3°C at 0°C according to IEC 751 Connection head, brass, height=16mm Dm.: Ø5xel=75mm, Stainless steel, Mounting Hole: for M6 screws without plug, Cable: Shielded Hose Line 1x [4xAWG 24/7 CU-Silverplated/STP/Polyester Film/Cu-tinned/STP kl=1100mm, AØ: 4.2mm] BK (RD/RD/WH/WH), Plastic corrugated pipe hose Aø=10mm VCST-07B, Measuring range ፦40°C... +150°C Ambient temperature ፦40°C... +105°C Insulation resistance: ≥ 200 MΩ/500 VDC Dielectric Strength: Element versus Element: 0.5 kV AC. 50 Hz/1min. IP protection class: IP 68 (1 bar. 30 min) (applies only to the sensor head) Umbrella attached to the sensor housing Parasol discharged on the connection Colour code different from DIN EN 60751 1.Pt100: RD/RD 2ND P100: WH/WH |
